10 cm (4") fullrange speaker offers great frequency response and sensitivity in a compact package. Great for point-source applications with a limited amount of mounting depth space.

SHIPMENT IN 5-7 WORKING DAYS
€11.95
Tax included
rating No review at the moment

Estimated Shipping Costs
Shipping Costs
€14.40
Shipping Time
.
Want to check another country or courier?

You might also like



Visaton R 10 S - 8 4" Full-Range Speaker 8 Ohm

10 cm (4") fullrange speaker offers great frequency response and sensitivity in a compact package. Great for point-source applications with a limited amount of mounting depth space.

.

Highlights

  • Full-range frequency response from 100 to 13,000 Hz
  • Thin mount profile with a mounting depth of 36 millimeters
  • High 90 dB sensitivity

.

Product Details

Visaton R 10 S 4" Full-Range Speaker 8 Ohm

Designed or electronic devices, and to be used in the ceiling structures of rail cars and buses, Visaton's R 10 S full-range speaker has very linear response from 150 to 10,000 Hz. The slim design features a depth of 36 millimeters for shallow mounting. High sensitivity and good power handling combine for more output than many midrange drivers this size, while the paper cone and accordion surround create a more natural, classic sound that is pleasing to most peoples' ears.

A square steel mounting plate eliminates the need for a baffle recess, while the mounting slots can accept a wider range of mounting diameters.

.

Technical data

  • Article number R 10 S - 8
  • Woofer Series R Series
  • Woofer Type Full-Range
  • Nominal Diameter 8"
  • Power Handling (RMS) 20 Watts
  • Power Handling (max) 30 Watts
  • Impedance (Z) 8 ohms
  • Sensitivity (SPL at 1m / 2.83V) 90 dB
  • Frequency Response 100 - 13,000 Hz
  • Voice Coil Diameter 15 mm
  • DC Resistance (Re) 7.2 ohms
  • Voice Coil Inductance (Le) 0.5 mH
  • Resonant Frequency (Fs) 160 Hz
  • Mechanical Q (Qms) 6.27
  • Electromagnetic Q (Qes) 2.92
  • Total Q (Qts) 1.99
  • Surface Area of Cone (Sd) 56 cm2
  • BL Product (BL) 2.0 Tm
  • Maximum Linear Excursion (Xmax) 0.5 mm
  • Cone / Diaphragm Material Paper
  • Surround Material Treated Paper
  • Basket / Frame Material Steel
  • Magnet Material Ferrite
  • Overall Outside Diameter 94 mm
  • Overall Depth 36 mm
  • Baffle Cutout Diameter 93 mm
  • Bolt Circle Diameter 117 mm
  • # Mounting Holes 4 Mounting Hole Diameter 5 mm
Visaton R 10 S
