20 cm (8") high efficiency full-range loudspeaker with tweeter done.

SHIPMENT IN 5-7 WORKING DAYS
€43.95
Tax included
rating No review at the moment

Estimated Shipping Costs
Shipping Costs
€12.60
Shipping Time
.
Want to check another country or courier?

You might also like



Visaton BG 20 8" Full-Range Speaker 8 Ohm

20 cm (8") high efficiency full-range loudspeaker with tweeter done.

.

Highlights

  • High efficiency
  • Tweeter done
  • Ideal for mid-range of full-range systems

.

Product Details

Visaton BG 20 8" Full-Range Speaker 8 Ohm

These high efficiency full-range speakers stand out because of their high end used paper cone. The BG 20 is ideally suited to use as midrange unit for full scale or musicians' PA systems, vocal or guitar monitors or as fullrange speaker for electronic organs and keyboards.

.

Technical Data

  • Article number BG 20
  • Woofer Type Full-Range
  • Nominal Diameter 8"
  • Power Handling (RMS) 40 Watts
  • Power Handling (max) 70 Watts
  • Impedance (Z) 8 Ohm
  • Sensitivity (SPL at 1m / 2.83V) 92 dB
  • Frequency Response fu–18000 Hz
  • Voice Coil Diameter 25 mm
  • DC Resistance (Re) 6.2 Ohm
  • Resonant Frequency (Fs) 38 Hz
  • Mechanical Q (Qms) 3.47
  • Electromagnetic Q (Qes) 0.51
  • Total Q (Qts) 0.44
  • Diaphragm Mass Inc. Airload (Mms) 10 g
  • Surface Area of Cone (Sd) 214 cm²
  • Compliance Equivalent Volume (Vas) 110 L
  • Maximum Linear Excursion (Xmax) 4 mm
  • Overall Outside Diameter 205 mm
  • Overall Depth 89 mm
  • Baffle Cutout Diameter 184 mm
  • Bolt Circle Diameter 197 mm
  • # Mounting Holes 4
  • Mounting Hole Diameter 5 mm

Visaton BG 20
