25 mm (1") High-End titanium dome tweeter.

SHIPMENT IN 5-7 WORKING DAYS
€78.45
Tax included
rating No review at the moment

Estimated Shipping Costs
Shipping Costs
€14.40
Shipping Time
.
Want to check another country or courier?

You might also like



Visaton DSM 25 FFL Dome Tweeter

25 mm (1") High-End titanium dome tweeter.

.

Highlights

  • Titanium dome with sypronyle surround
  • High power handling
  • High efficiency

.

Product Details

Visaton DSM 25 FFL High-End Titanium Dome Tweeter 8 Ohm

Tweeter for the high-range above 2000 Hz. Due to the enormously strong and ultra-light titanium dome and in conjunction with a highly damped sypronyle surround, linear frequency response and no partial oscillations.

Due to the enormously high magnetic flux in the ferrofluid-filled air-gap high efficiency and high power handling are possible.

Technical Specifications

  • Article number DSM 25 FFL
  • Tweeter Type Metal Dome
  • Tweeter Series High-End
  • Cone / Dome Diameter 25 mm | 1"
  • Power Handling (RMS) 80 Watts
  • Power Handling (max) 140 Watts
  • Impedance (Z) 8 Ω
  • Sensitivity (SPL at 1m / 2.83V) 90 dB
  • Frequency Response 1,000 - 30,000 Hz
  • Resonant Frequency (Fs) 1600 Hz
  • DC Resistance (Re) 5.9 ohms
  • Overall Outside Diameter 110 mm
  • Cutout Diameter 80 mm
  • Depth 26.5 mm
  • Diaphragm Material Titanium
  • Recommended cut frequency >2,000 Hz
