The Visaton SL 87 WPM-8 is a compact and versatile speaker driver measuring just 3.3 inches in diameter. This full-range driver punches above its weight by reproducing a wide range of frequencies, making it suitable for various DIY speaker projects.

SHIPMENT IN 5-7 WORKING DAYS
€11.95
Tax included
rating No review at the moment

Estimated Shipping Costs
Shipping Costs
€12.60
Shipping Time
.
Want to check another country or courier?

You might also like



Visaton SL 87 WPM - 8 Full-range Woofer 3,3" 8 Ohm

The Visaton SL 87 WPM-8 is a compact and versatile speaker driver measuring just 3.3 inches in diameter. This full-range driver punches above its weight by reproducing a wide range of frequencies, making it suitable for various DIY speaker projects. Common applications include bookshelf speakers for stereo listening, center channels in home theater setups, or even compact surround sound speakers. The single driver design simplifies construction, requiring only the SL 87 WPM-8 to create a functioning speaker.

.

Highlights

  • Full-range design
  • Water-resistant
  • Transparent cone
  • High sound pressure level
.

Product Details

Visaton SL 87 WPM - 8 Full-range Woofer

An advantage of the SL 87 WPM - 8 is its water resistance. The cone, made from a special plastic, can withstand moisture and humidity. This makes it a good choice for use in bathrooms, kitchens, or even outdoors when housed in a proper speaker enclosure. Despite its small size, the SL 87 WPM - 8 delivers surprising power. With a nominal power handling of 20W, this driver can produce clear, audible sound even in limited space applications.

.

Technical specifications include:

  • Rated power 20 W
  • Maximum power 30 W
  • Nominal impedance Z 8 Ohm
  • Frequency response 200–5000 Hz
  • Mean sound pressure level 89 dB (1 W/1 m)
  • Beam angle (-6 dB)
  • Opening angle (-6 dB) 142°/4000 Hz
  • Excursion limit +/−1.5 mm
  • Resonance frequency fs 290 Hz
  • Magnetic induction 0.87 T
  • Magnetic flux Magnetic flux 165 μWb
  • Height of front pole-plate 3 mm
  • Voice coil diameter 20 mm
  • Height of winding 5 mm
  • Cutout diameter 80 mm
  • Net weight 0.24 kg
  • Connections 2.8 x 0.5 mm (+) 2.8 x 0.5 mm (−)
  • Protective system IP 65 IP 68
  • Temperature range −40 ... 70 °C
  • Technical data SL 87 WPM - 8 Ohm
Visaton SL 87 WPM - 8
