50 mm (2") High-End titanium mid-dome for the band between 800 and 5000 Hz.

SHIPMENT IN 5-7 WORKING DAYS
€129.95
Tax included
rating No review at the moment

Estimated Shipping Costs
Shipping Costs
€14.40
Shipping Time
.
Want to check another country or courier?

You might also like



Visaton DSM 50 FFL 2" High-End Titanium Mid-Dome 8 Ohm

50 mm (2") High-End titanium mid-dome for the band between 800 and 5000 Hz.

.

Highlights

  • Titanium dome with highly damped surround
  • High power handling
  • High efficiency

.

Product Details

Visaton DSM 50 FFL 2" High-End Titanium Mid-Dome 8 Ohm
Thanks to the enormously strong and ultra-light titanium dome in conjunction with a highly damped surround, this dome has very linear frequency response and no partial oscillations.
Due to the enormously high magnetic flux in the ferrofluid-filled air-gap a high efficiency and high power handling are possible.

.

Technical Specifications

  • Article number DSM 50 FFL
  • Woofer Series High-End
  • Woofer Type Mid-dome
  • Nominal Diameter 2"
  • Power Handling (RMS) 120 Watts
  • Power Handling (max) 180 Watts
  • Impedance (Z) 8 ohms
  • Sensitivity (SPL at 1m / 2.83V) 90 dB
  • Frequency Response 400 - 15,000 Hz
  • Voice Coil Diameter 50 mm
  • DC Resistance (Re) 6.7 ohms
  • Voice Coil Inductance (Le) 0.16 mH
  • Resonant Frequency (Fs) 430 Hz
  • Mechanical Q (Qms) 1.19
  • Electromagnetic Q (Qes) 0.7
  • Total Q (Qts) 0.44
  • Diaphragm Mass Inc. Airload (Mms) 1.2g
  • Surface Area of Cone (Sd) 20 cm2
  • Cone / Diaphragm Material Titanium
  • Overall Outside Diameter 150 mm
  • Overall Depth 50 mm
  • Baffle Cutout Diameter 106 mm
  • Bolt Circle Diameter 126 mm
  • # Mounting Holes 4 Mounting Hole Diameter 4.4 mm
