TANG BAND W4-2417 - Full Range TB 4" - Cone Al+PPM - Ferrite
TANG BAND W4-2417 - Full Range TB 4" - Cone Al+PPM - Ferrite
TANG BAND W4-2417 - Full Range TB 4" - Cone Al+PPM - Ferrite
TANG BAND W4-2417 - Full Range TB 4" - Cone Al+PPM - Ferrite
TANG BAND W4-2417 - Full Range TB 4" - Cone Al+PPM - Ferrite
TANG BAND W4-2417 - Full Range TB 4" - Cone Al+PPM - Ferrite

TANG BAND W4-2417 - Full Range TB 4" - Cone Al+PPM - Ferrite

TANG BAND W4-2417 - Full Range TB  4" - Cone Al+PPM - Ferrite

Variants
TANG BAND W4-2417 - Full Range TB 4" - Cone Al+PPM - Ferrite
TANG BAND W4-2142 - 4" Full Range TB-Speakers
TANG BAND W4-2414 - Full Range 4" - Cone Al+PPM - Ferrite
SHIPMENT IN 7/10 WORKING DAYS
€66.50 €70.00 -5%
Tax included
rating No review at the moment

The minimum purchase order quantity for the product is 2.

Quantity Unit discount You Save
2 5% €7.00
4 7% €19.60
Estimated Shipping Costs
Shipping Costs
€12.60
Shipping Time
.
Want to check another country or courier?

You might also like



TANG BAND W4-2417 - Full Range TB  4" - Cone Al+PPM - Ferrite

.

The TB Speaker W4-2417 is a full-range speaker designed to deliver extremely linear performance and high-precision sound reproduction across a wide frequency range, from 65 Hz to 40 kHz. Thanks to its sophisticated underhung design, this model ensures superior control of the voice coil's movement, significantly reducing distortion and ensuring extremely faithful dynamic response even at high volumes.

One of the distinguishing features of the W4-2417 is its extremely low total harmonic distortion level, less than or equal to 0.01%, enabling clean, detailed sound reproduction free of unwanted coloration. The structure is further optimized by the use of an aluminum alloy dust cap, designed to improve high-frequency dispersion and contribute to the overall rigidity of the system.

The cone is made of specially formulated polypropylene and integrates aluminum alloy insert technology, a solution that allows for greater high-frequency extension while maintaining high mechanical stability. This combination of materials and design allows the driver to deliver a balanced, precise and coherent sound output, making it ideal for high-quality audio applications where reliability and consistency of performance are crucial.

.

Parameters Values

MTL Diaphragm Aluminum + PP

MTL Santoprene Suspension

Nominal Impedance 8 Ω

DCR Impedance 6.3 Ω

Sensitivity 86 dB

Frequency Response 65 - 40 kHz

Free-Air Resonance 65 Hz

Voice Coil Diameter 25.4 mm

Traffic Height 10 mm

Rated Input Power 25 W

Maximum Input Power 50 W

Blade Force Factor 5.36 TM

Magnet Type Ferrite

Moving Mass 5.56 g

Ferrofluid Enhanced

Full Suspension NO

988 uMN¯¹

Effective Piston Area 0.0057 m²

Levc 0.032 mH

Zo 40 Ω

X-max 2.5 mm

Vapor 4.56 l

Qts 0.44

Qms 2.87

Qes 0.52

W4-2417
