Visaton FRS 7 - 4 Full-range Woofer

The Visaton FRS 7 - 4 is a compact 2.5-inch full-range speaker driver designed for a variety of audio applications.

The minimum purchase order quantity for the product is 2.

Estimated Shipping Costs
Shipping Costs
€12.60
Shipping Time
.
Want to check another country or courier?

You might also like



Visaton FRS 7 - 4 Full-range Woofer

The Visaton FRS 7 - 4 is a compact 2.5-inch full-range speaker driver designed for a variety of audio applications. Its strength lies in its ability to reproduce a wide range of frequencies, from bass to treble, making it a versatile option for small speaker builds. This full-range capability allows its use in bookshelf speakers, center channels for home theater systems, or even compact surround sound speakers.

.

Highlights

  • Full-range design
  • Balanced frequency response
  • High efficiency
  • Small size
  • Waterproof membrane

.

Product Details

Visaton FRS 7 - 4 Full-range Woofer

Beyond its size, the Visaton FRS 7 - 4 is known for its balanced sound profile. This means all audible frequencies are delivered at similar levels, creating a smooth and natural listening experience. Additionally, the speaker boasts high efficiency. Even with low-powered amplifiers, the FRS 7 - 4 can produce ample sound, making it ideal for portable speaker systems or instrument amplifiers.

Technical Specifications

  • Rated power 8 W
  • Maximum power 15 W
  • Nominal impedance Z 4 Ohm
  • Frequency response 200–20000 Hz
  • Mean sound pressure level 88 dB (1 W/1 m)
  • Discharge angle (-6 dB)
  • Opening angle (-6 dB) 149°/4000 Hz
  • Excursion limit Excursion limit +/−1.5 mm
  • Resonance frequency fs
  • Resonance frequency fs 250 Hz
  • Magnetic induction 1.2 T
  • Magnetic flux 160 μWb
  • Height of front pole-plate 2 mm
  • Voice coil diameter 14 mm
  • Height of winding 3.5 mm
  • Cutout diameter 61 mm
  • Net weight 0.2 kg
  • DC resistance Rdc 3.6 Ohm
  • Mechanical Q factor Qms 3.21
  • Electrical Q factor Qes 1.96
  • Qts Total Q factor Qts 1.22
  • Vas Equivalent volume Vas 0.3 l
  • Effective membrane area Sd
Visaton FRS 7 - 4
