The Visaton SL 87 WPM-4 is a 3.3-inch full-range speaker driver designed for clear sound and durability.

SHIPMENT IN 5-7 WORKING DAYS
€11.95
Tax included
rating No review at the moment

Estimated Shipping Costs
Shipping Costs
€12.60
Shipping Time
.
Want to check another country or courier?

You might also like



Visaton SL 87 WPM - 4 Full-range Woofer 3.3"

The Visaton SL 87 WPM-4 is a 3.3-inch full-range speaker driver designed for clear sound and durability. This small but powerful driver can reproduce a wide range of frequencies, making it suitable for various applications like bookshelf speakers, center channels in home theater systems, or even compact surround sound setups. Because of its full-range design, you only need this single driver to create a functioning speaker.

.

Highlights

  • Wide and balanced frequency response
  • Excellent low-range reproduction
  • Powerful Neodymium driver
  • Compact design suitable for various applications

.

Product Details

Visaton SL 87 WPM - 4 Full-range Woofer

Beyond its size, the Visaton SL 87 WPM - 4 is known for its balanced sound profile. This means all audible frequencies are delivered at similar levels, creating a smooth and natural listening experience. Additionally, the speaker boasts high efficiency. Even with low-powered amplifiers, the SL 87 WPM - 4 can produce ample sound, making it ideal for portable speaker systems or instrument amplifiers.

.

Technical specifications

Rated power 20 W

Maximum power 30 W

Nominal impedance Z 8 Ohm

Frequency response 200–5000 Hz

Mean sound pressure level 89 dB (1 W/1 m)

Beam angle (-6 dB)

Opening angle (-6 dB) 142°/4000 Hz

Excursion limit +/−1.5 mm

Resonance frequency fs 290 Hz

Magnetic induction 0.87 T

Magnetic flux 165 µWb

Height of front pole-plate 3 mm

Voice coil diameter 20 mm

Height of winding 5 mm

Cutout diameter 80 mm

Net weight 0.24 kg

Connections 2.8 x 0.5 mm (+) , 2.8 x 0.5 mm (−)

Protective system IP 65 *).   IP 68 *) **)

Temperature range −40 ... 70 °C
