Markaudio TW 6 Metal Dome Tweeter

Price for 1 piece

Produktbeschreibung Markaudio TW 6 Dome Tweeter

The Markaudio TW6 is a high-efficiency metal dome tweeter designed for DIY speaker builders who demand detailed highs and low distortion. With a custom polymer frame, built-in waveguide, and ferrofluid-damped voice coil, it provides clean treble response up to 30 kHz while maintaining excellent power handling in compact enclosures.

.

Highlights of the Markaudio TW6

Extended frequency response from 2.5 kHz to 30 kHz for sparkling treble

Custom polymer frame with integrated waveguide for smooth dispersion

Ferrofluid-damped 25 mm voice coil for cooling and power stability

Compact, recessed-mount design with professional high-end finish

.

Product details Markaudio TW6

The Markaudio TW6 is built to deliver high-resolution sound for custom loudspeaker projects. Featuring a 25 mm aluminum diaphragm, it achieves 98 dB sensitivity (1m/2.83V) and handles 15 W nominal (30 W max) power. Its ferrofluid-damped voice coil improves thermal management and reliability, while the absence of a phase shield preserves natural clarity. The small built-in waveguide ensures smooth integration into multi-way systems, making it a perfect match for Markaudio’s MA200, CHR-120, Alpair 12P, and CHN-110 drivers. With its refined frame design and recessed mounting, the TW6 not only sounds precise but also looks professional in finished builds.

.

Features

Article Number: TW 6

EAN 9509612657943

Tweeter Type Dome tweeter

Cone/Dome Diameter 1"

Power Handling (QMW) 15 Watts

Maximum Power Handling 30 Watts

Impedance (Z) 4 Ω

Sensitivity (SPL at 1m / 2.83V) 98 dB

Frequency Response 2,500–30,000 Hz

Resonant Frequency (Fs) 1,700 Hz

DC Resistance (Re) 3.2 Ω

Outer Diameter 74 mm

Depth 9.3 mm

Confirmation Type Holes 4 x 4.2 mm
