Packing big sound into a tiny package, the Visaton FRS 5-8 is a full-range speaker driver perfect for space-conscious projects. This 2-inch speaker is ideal for situations where size is a premium, such as portable speakers, compact speaker systems, or even custom speaker builds.

SHIPMENT IN 5-7 WORKING DAYS
€12.95
Tax included
rating No review at the moment

Estimated Shipping Costs
Shipping Costs
€12.60
Shipping Time
.
Want to check another country or courier?

You might also like



Visaton FRS 5 - 8 Full-range Woofer

Packing big sound into a tiny package, the Visaton FRS 5-8 is a full-range speaker driver perfect for space-conscious projects. This 2-inch speaker is ideal for situations where size is a premium, such as portable speakers, compact speaker systems, or even custom speaker builds. Despite its miniature stature, the FRS 5-8 delivers impressive sound quality with a well-balanced frequency response, ensuring natural and clear audio reproduction

.

Highlights

  • Very narrow network column speakers
  • Monitoring speaker for electronic devices
  • Model construction
  • Electronic musical instruments Moisture-resistant membrane metal design

.

Product Details

Visaton FRS 5 - 8 Full-range Woofer

The FRS 5-8's versatility extends beyond just music. With a power handling capacity of 5 watts, it's well-suited for applications where clear sound is more important than booming volume. This makes it a great choice for monitor speakers in electronic devices, adding sound to model creations, or even incorporating it into electronic musical instruments.

At 8 ohms impedance, the FRS 5-8 integrates seamlessly with most standard audio amplifiers. While it can produce surprisingly deep bass tones for its size due to its 120 Hz resonance frequency, pairing it with a subwoofer might be necessary for projects requiring a stronger bass presence. Overall, the Visaton FRS 5-8 is a compact powerhouse offering excellent sound quality in a tiny package, making it a versatile and user-friendly option for hobbyists and professionals alike.

Technical Specifications

  • Rated power 5 W
  • Impedance 8 Ω
  • Frequency response (–10 dB) 150–20000 Hz
  • Mean sound pressure level 84 dB (1 W/1 m)
  • Excursion limit x mech ± 2 mm
  • Resonant frequency 270 Hz
  • Height of front pole-plate 2.5 mm
  • Voice coil diameter 14 mm Ø
  • Height of winding 3.7 mm
  • Cut-out diameter 46 mm Ø
  • Terminal Solder lugs
  • Net weight 0.126 kg
Visaton FRS 5 - 8
