13 cm (5") HiFi full-range shielded driver with cellulose cone and rubber surround.

SHIPMENT IN 5-7 WORKING DAYS
€32.95
Tax included
rating No review at the moment

Estimated Shipping Costs
Shipping Costs
€12.60
Shipping Time
.
Want to check another country or courier?

You might also like



Visaton SC 13 5" HiFi Full-Range Driver 8 Ohm

13 cm (5") HiFi full-range shielded driver with cellulose cone and rubber surround.

.

Highlights

  • Great for surround centre speakers
  • Magnetically shielded
  • Very balanced frequency response

.

Product Details

Visaton SC 13 5" HiFi Full-Range Driver 8 Ohm
This shielded driver can be used as a low-midrange driver too. Due to the very balanced frequency response especially suitable for magnetically shielded 2-way speakers for multi-media and surround systems in conjunction with the shielded tweeter SC 10 N - 8 Ohm.

.

Technical Data

  • Article number SC 13
  • Woofer Series HiFi Series
  • Woofer Type Full-Range
  • Nominal Diameter 5"
  • Power Handling (RMS) 40 Watts
  • Power Handling (max) 60 Watts
  • Impedance (Z) 8 ohms
  • Sensitivity (SPL at 1m / 2.83V) 90 dB
  • Frequency Response 78 - 13,000 Hz
  • Voice Coil Diameter 20 mm
  • DC Resistance (Re) 7.2 ohms
  • Voice Coil Inductance (Le) 0.7 mH
  • Resonant Frequency (Fs) 78 Hz
  • Mechanical Q (Qms) 2.95
  • Electromagnetic Q (Qes) 0.94
  • Total Q (Qts) 0.71
  • Surface Area of Cone (Sd) 79 cm2
  • BL Product (BL) 4.2 Tm
  • Compliance Equivalent Volume (Vas) 7.4 liters
  • Maximum Linear Excursion (Xmax) 0.75 mm
  • Cone / Diaphragm Material Cellulose
  • Surround Material Rubber Shielded Yes
  • Overall Outside Diameter 162 mm
  • Overall Depth 62 mm Baffle
  • Cutout Diameter 113 mm
  • Bolt Circle Diameter 145 mm
  • # Mounting Holes 5 mm
