Dayton Audio DC28FS-8 1-1/8" Silk Dome Shielded Tweeter
Dayton Audio DC28FS-8 1-1/8" Silk Dome Shielded Tweeter
Dayton Audio DC28FS-8 1-1/8" Silk Dome Shielded Tweeter
Dayton Audio DC28FS-8 1-1/8" Silk Dome Shielded Tweeter
Dayton Audio DC28FS-8 1-1/8" Silk Dome Shielded Tweeter
Dayton Audio DC28FS-8 1-1/8" Silk Dome Shielded Tweeter

Dayton Audio DC28FS-8 1-1/8" Silk Dome Shielded Tweeter

Dayton Audio DC28FS-8 1-1/8" Silk Dome Shielded Tweeter

Shielded version of the famous Dayton Audio Silk Dome Tweeter. 1-1/8" silk dome with ferrofluid cooling and fully shielded motor structure.

Highlights

  • Offers smooth and detailed high frequency performance
  • Magnetically shielded
  • Ferrofluid cooled voice coil
SHIPMENT IN 7-10 WORKING DAYS
€32.00
Tax included
rating No review at the moment

Estimated Shipping Costs
Shipping Costs
€12.60
Shipping Time
.
Want to check another country or courier?



Dayton Audio DC28FS-8 1-1/8" Silk Dome Shielded Tweeter

Shielded version of the famous Dayton Audio Silk Dome Tweeter. 1-1/8" silk dome with ferrofluid cooling and fully shielded motor structure.

The shielded version of the famous Dayton Audio Silk Dome, this tweeter offers the same performance but in a CRT-safe design. Features a 1-1/8" silk dome with a ferrofluid cooled voice coil for superior damping. A damped rear chamber lowers the resonance point and provides a very smooth natural sound with excellent on and off axis response. Recommended for crossover points as low as 1,800 Hz, making it ideal for most 2-way speaker designs.

Highlights

  • Offers smooth and detailed high frequency performance
  • Magnetically shielded
  • Ferrofluid cooled voice coil

Product Details

Speaker Series Classic Series
Model Number DC28FS-8
Color Black
Unit of Measure Each
UPC 844632015878
Product Shipping Weight (lbs.) 1.3
Speaker Type Tweeter
Nominal Diameter 1.125"
Power Handling (RMS) 50 watts
Power Handling (max) 100 watts
Continuous Program Power --
Impedance 8 ohms
Sensitivity 89 dB @ 1W/1m
Frequency Response 1,600 - 20,000 Hz
Voice Coil Diameter 29 mm
Magnet Weight --
DC Resistance (Re) 5.4 ohms
Voice Coil Inductance (Le) 1.58 mH @ 1 kHz
Resonant Frequency (Fs) 905 Hz
Mechanical Q (Qms) 2.21
Electromagnetic Q (Qes) 1.73
Total Q (Qts) 0.97
Diaphragm Mass Inc. Airload (Mms) --
Moving Mass Of Diaphragm (Mmd) --
Mechanical Compliance of Suspension (Cms) --
Surface Area Of Cone (Sd) 6.6 cm²
Volume of Displacement (Vd) --
BL Product (BL) --
Compliance Equivalent Volume (Vas) --
Maximum Linear Excursion (Xmax) --
Drivers Mechanical Losses (Rms) --
Cone / Diaphragm Material Treated Silk Dome
Entry / Exit Diameter --
Surround Material --
Voice Coil Wire Material --
Voice Coil Former --
Basket/Frame Material --
Magnet Material --
Overall Outside Diameter 110 mm
Overall Depth 36 mm
Baffle Cutout Diameter 78 mm
# Mounting Holes 3
Mounting Hole Diameter --
Bolt Circle Diameter --
Product Weight --
Cone / Dome Diameter 1.125"
DC28FS-8
6 Items
New
844632000157
