    BlieSMa T34A-4 34 mm aluminium-magnesium tweeter 4 Ohm

    Out-of-Stock
    €389.00
    Tax included
    rating No review at the moment

    BlieSMa T34A-4 34mm aluminium-magnesium tweeter 4 Ohm

    High-sensitivity tweeter with 34-mm aluminium-magnesium alloy dome.

    The new star among the dome tweeters with aluminum membrane and high dynamics. The T34A-4 offers the sound neutrality of a perfect tweeter in combination with impressive dynamics and a wide transmission range.

    The minimum purchase order quantity for the product is 2.

    Estimated Shipping Costs
    Shipping Costs
    €18.00
    Shipping Time
    .
    Want to check another country or courier?



    BlieSMa T34A-4 34mm aluminium-magnesium tweeter 4 Ohm

    High-sensitivity tweeter with 34-mm aluminium-magnesium alloy dome.

    The new star among the dome tweeters with aluminum membrane and high dynamics. The T34A-4 offers the sound neutrality of a perfect tweeter in combination with impressive dynamics and a wide transmission range.

    Characteristics :

    • 34mm aluminum magnesium alloy variable thickness dome
    • Extremely wide recommended frequency range 1.3 kHz-40 kHz
    • Extreme dynamics with an efficiency of 97.5 dB @ 2.83V
    • Membrane resonance at about 39kHz in ultrasound
    • Extremely low moving mass for improved dynamics, response and higher efficiency
    • Fully saturated copper-capped neodymium motor for low non-linear distortion and exceptionally low intermodulation distortion 3 mm linear excursion and large vent channel for undistorted reproduction at low frequencies
    • Narrow surround for less tone coloration through soft elements.
    • Sound generation only through the aluminum membrane, which is rigid up to 28kHz
    • Flush-mounted surround and rear-mounted magnet system for a flat frequency response and a wide off-axis response.
    • No ferrofluid for improved dynamics
    • Copper-coated aluminum underhung voice coil on titanium bobbin
    • Flexible and lightweight connection wires, made in Denmark
    • Thick, powder-coated aluminum flange A
    • luminum rear chamber with natural wool damping
    • Gold plated wire connectors

    Specifications :

    • Nominal Impedance: 4Ω
    • Rated power* 80 W
    • Sensitivity 2.83V/1m 96dB
    • Net weight 0.68kg
    • Effective piston area, Sd 10.5 cm²
    • Moving mass, Mms 0.28 g
    • Force factor, Bl 3.5 T*m
    • Resonant frequency, Fs 790 Hz
    • Mechanical Q factor, Qms 2.1
    • Electrical Q factor, Qes 0.42
    • Overall Q-factor, Qts 0.35
    • Magnetic flux density 2.2 T
    • Air gap height 4.5 mm
    • Linear deflection (p-p) 3 mm
    • Voice coil diameter 34 mm
    • Voice coil height 1.4 mm
    • voice coil layers 2
    • Voice coil inductance
    • Le 0.008 mH DC resistance
    • Re 3.3 Ω Wire material CCAW
    • * IEC 268-5, 2nd order high-pass Butterworth filter, 2.5 kHz
    BlieSMa T34A-4
