BlieSMa M74P-6 74mm midrange speakers Paper dome 6 ohm

BlieSMa M74P-6 74 mm midrange speakers Paper dome 6 ohm

Name: BlieSMa M74P-6 74 mm midrange speakers Paper dome 6 ohm
Brand: Bliesma
SKU: BlieSMa M74P-6
Price: 379 EUR
Availability: OutOfStock

BlieSMa M74P-6 74mm midrange speakers Paper dome 6 ohm

Bliesma M74P-6 midranges have extremely low mass (2.3 g) of moving part, with linear excursion of 2.4 mm.

Single-layer ribbon CCAW (Copper-clad Aluminum Wire) voice coil of Bliesma M74P-6 is wound on titanium former.

Bliesma M74P-6 midranges feature 74 mm natural silk soft dome with integrated surround and protection grill. Thick aluminium mounting flange is powder coated, aluminium rear chamber is filled with natural wool damping.

Out-of-Stock

€379.00

Tax included

No review at the moment

The minimum purchase order quantity for the product is 2.

Estimated Shipping Costs

Shipping Costs

€19.08

Shipping Time

Want to check another country or courier?

BlieSMa M74P-6 74mm midrange speakers Paper dome 6 ohm

Bliesma M74P-6 midranges have extremely low mass (2.3 g) of moving part, with linear excursion of 2.4 mm.

Single-layer ribbon CCAW (Copper-clad Aluminum Wire) voice coil of Bliesma M74P-6 is wound on titanium former.

Characteristics :

74mm paper dome
Best impulse response and highest efficiency (95dB @ 2.83V) of the dome midrange drivers
Recommended frequency range 400 Hz-4.5 kHz
Cone resonance at about 5.5 kHz
Extremely low moving mass for improved dynamics, better response and higher efficiency
Fully saturated copper-capped neodymium motor for low non-linear distortion and exceptionally low intermodulation distortion 2.4 mm linear excursion and large vent channel for undistorted playback at low frequencies
Flush-mounted surround and rear-mounted magnet system for a flat frequency response and a wide off-axis response.
No ferrofluid for improved dynamics
Copper-coated aluminum underhung voice coil on titanium bobbin
Flexible and lightweight connection wires, made in Denmark
Thick, powder-coated aluminum flange
Aluminum rear chamber with natural wool damping
Gold plated wire connectors

Specifications :

Nominal Impedance: 6Ω
Rated power*: - W
Sensitivity 2.83V/1m: 95dB
Net Weight: 0.68kg
Effective piston area: Sd 50.25 cm²
Moving mass, mms: 2.3 g
Force factor: Bl 6.8 T*m
Resonance frequency: Fs 400Hz
Mechanical Q factor: Qms 3
Electrical Q factor, Qes 0.0.6
Overall Q-factor: Qts 0.5
Magnetic Flux Density: 1.35T
Air Gap Height: 4.2mm
Linear Excursion (p-p): 2.4mm
Voice coil diameter: 74 mm
Voice coil height: 1.8 mm
Voice coil layers: 1
Voice coil inductance: Le 0.036 mH
DC resistance: Re 5.6Ω
Wire Material: CCAW
* IEC 268-5, 2nd order high-pass Butterworth filter, 400 Hz
