SHIPMENT IN 7-10 WORKING DAYS

€82.90

Tax included

No review at the moment

SB Acoustics SB26STWGC-4 Dome Tweeter

Flow optimized vented pole piece for optimum coupling to rear chamber, Fine weave soft fabric dome for smooth frequency response, Saturation controlled motor system for low distortion, CCAW voice coil for low moving mass, Long life silver lead wires, Low resonance frequency.

Estimated Shipping Costs

Shipping Costs

€18.00

Shipping Time

.

Want to check another country or courier?

Description
Product Details

SB Acoustics SB26STWGC-4 Dome Tweeter.

.

Product description

Solid aluminium waveguide

Controlled directivity

Adapter ring for bolt-less mounting to driver

Copper cap for reduced voice coil inductance and minimum phase shift

Non-reflective rear chamber with optimized damping for improved dynamics

.

Product details

SB acoustics SB26STWGC-4 Tweeter

Flow optimized vented pole piece for optimum coupling to rear chamber, Fine weave soft fabric dome for smooth frequency response, Saturation controlled motor system for low distortion, CCAW voice coil for low moving mass, Long life silver lead wires, Low resonance frequency.

,

Specifications

Article numberSB26STWGC-4

Tweeter TypeDome

Cone / Dome Diameter25 mm | 1"

Power Handling (RMS)120 Watts

Impedance (Z)4 Ω

Sensitivity (SPL at 1m / 2.83V)93 dB

Resonant Frequency (Fs)780 Hz

DC Resistance (Re)3.2 Ohms

Voice Coil Inductance (Le)0.04 mH

Mechanical Q (Qms)2.8

Electromagnetic Q (Qes)2.1

Total Q (Qts)1.20

Reference SB26STWGC-4

In stock 10 Items
