Morel CAT 378 - 28mm Tweeter - Advanced - 8ohm
Morel CAT 378 - 28mm Tweeter - Classic Advanced - 8ohm
Morel's CAT378 features a hand treated 1-1/8" soft dome, horn loaded for higher efficiency and high dynamic range without power compression.
Key Features
- 94 mm wide dispersion horn-loading faceplate
- Large Hexatech aluminum voice coil allows high power handling
- High efficiency design for dynamic output
- Replaceable Acuflex dome/coil assembly
You might also like
Morel CAT 378 - 28mm Tweeter - Classic Advanced - 8ohm
Morel's CAT378 features a hand treated 1-1/8" soft dome, horn loaded for higher efficiency and high dynamic range without power compression. The magnet assembly is vented into a damped rear chamber to lower resonance and to eliminate "honking" at lower frequencies. Latest evolution of the popular MDT-37 tweeter. Replacement diaphragm (277-046).
-
Product Details
Brand Morel
Model CAT 378
Part Number 277-084
UPC 844632070761
Unit of Measure Each
Weight 1.45
-
Product Specifications
Cone / Dome Diameter 1.125"
Cutout Diameter 2.83
Tweeter Type Soft Dome
Power Handling (RMS) 200 Watts
Impedance 8Ω
Frequency Response 1,800 to 20,000Hz
Sensitivity 93dB 2.83V/1m
-
Thiele-Small Parameters
Resonant Frequency (Fs) 700Hz
DC Resistance (Re) 5.2Ω
Voice Coil Inductance (Le) 0.09mH
Mounting Information
Overall Outside Diameter 3.70"
Depth 2.32"
