Visaton ALTO I | DIY Components Pack | Sold as Pair

Components for 2 speakers , (cabinet not included)

.

Product description

To be clear from the start: these small sized STELLA LIGHT speakers pack a considerable punch. While the outer appearance of the speakers might be described as compact or even sweet, this definitely does not apply to the maximum sound pressure of which they are capable.

.

Highlights

F.A.S.T. (Full-range and Subwoofer Technology)

Very slim enclosure

Simple but effective series crossover

.

Product details

Visaton STELLA LIGHT DIY Components Pack

The combination of the FRS 8 full-range loudspeaker and W 170 S - 8 woofer stands out because of its unbelievable level accuracy. The fact that the separating frequency is at a very low 200 Hz benefits the STELLA LIGHT's positioning accuracy and generates an image of the stage that easily earns the "live" label. The FRS 8 - 8 Ohm full-range loudspeaker is remarkably detailed in its output: even the higher frequencies are reproduced accurately and with clear focus. Complemented by the W 170 S - 8 woofer, this combination covers almost the full range of frequencies required.

Whether used as computer speakers to the left and right of the desk or as a stereo set for the sitting room or bedroom, thanks to the excellent value-for-money price, these speakers can be used in many different environments without making too large inroads into your wallet. The simple, effective and intriguingly designed series crossover rounds the system off to produce a low-priced, quality building kit.

After all the cables have been positioned in the cabinet, the cable opening in the divider will have to be sealed off with e.g. hot-melt glue.

.

Extract from Klan & Ton

“Not really “light”: 180 euros for two column speaker sets that are, in terms of their sound reproduction quality, fully grown-up – you can hardly beat that. And on top of it all there's a considerable portion of the fascination of full-range speakers – what more could one want?”

.

Technical specifications:

Rated power 60 W

Music power handling 100 W

Nominal impedance Z 4 ohms

Transmission range (-10dB) 50-20000Hz

Mean sound pressure level 84 dB (1 W/1 m)

Separation frequency 200 Hz

Housing principle bass reflex

Net volume 17L + 0.7L

External height 900 mm

Outer dimension width 120 mm

Outer dimension depth 280 mm

.

Scope of delivery for 1 pair of loudspeakers:

• 2 FRS 8 8 Ohm wide tapes

• 2 woofers: W 170 S 8 Ohm

• 2x turnout components: ELKO blank 150 µF

• 2x turnout components: SP 3.3 mH / 0.6 mm

• 2 terminals: St 77

• 2 bass reflex tubes : BR 19.24 (shortened to 170 mm)

• 4 pcs. Damping Material: Polyester Wool

• 2 cables of 3 m 2 x 1.5 mm²

• 8 special wood screws 4 x 25 mm

• 16 countersunk screws 3.5 x 25 mm

Note: Cabinets are not included.
