WONDOM AA-AB31392 - 1x1000W amplifier class D T-AMP
WONDOM AA-AB31392 - 1x1000W amplifier class D T-AMP
WONDOM AA-AB31392 - 1x1000W amplifier class D T-AMP
WONDOM AA-AB31392 - 1x1000W amplifier class D T-AMP
WONDOM AA-AB31392 - 1x1000W amplifier class D T-AMP
WONDOM AA-AB31392 - 1x1000W amplifier class D T-AMP

WONDOM AA-AB31392 - 1x1000W amplifier class D T-AMP

WONDOM AA-AB31392 - 1x1000W amplifier class D T-AMP

This audio amplifier board uses T-AMP - AA-AB31392 technology, characterized by low distortion and low noise level. This amplifier board supports mono amplification using the PBTL topology. The fan works when the heat sink temperature reaches 45 degrees Celsius and stops when the temperature drops to 40 degrees Celsius.

Out-of-Stock
€118.50
Tax included
rating No review at the moment


Estimated Shipping Costs
Shipping Costs
€12.60
Shipping Time
.
Want to check another country or courier?

You might also like



WONDOM AA-AB31392 - 1x1000W amplifier class D T-AMP

This audio amplifier board uses T-AMP - AA-AB31392 technology, characterized by low distortion and low noise level. This amplifier board supports mono amplification using the PBTL topology. The fan works when the heat sink temperature reaches 45 degrees Celsius and stops when the temperature drops to 40 degrees Celsius.

Therefore the audible noise and the loss of inactive power carried by the fan could be omitted when the output RMS power is moderate.

Dettaglio di connessione amplificatore in classe D

 Features AA-AB31392

Parametri  Condizioni di Test Valori
Corrente massima 1000 W @ 1.5 Ohm 50 V
Tensioni di Alimentazione  - 25-50 V
Efficienza 1000 W @ 1.5 Ohm 91-96 %
Potenza Inattiva

SD Floating, FAN ON

SD Floating, FAN OFF

13.5-18 W

12.5-16 W
Frequenza Swhitching SD Floating 680 kHz
Potenza in Standby SD collegato a GND, FAN OFF 1-3 W
Sensibilità  di ingresso (RMS) @ 1,5Ω, 1000 W, 1 KHz 1.48 V
Impedenza di ingresso - 10 KΩ
Guadagno - 28-32 dB
Impedenza di carico minima - 1.5 Ω
Potenza in uscita

@ 1.5 Ω THD + N 1%

@ 1.5 Ω THD + N 10%

632 W

1000 W
Larghezza di banda @ ± 3dB @ 1.5 Ω 20-20K Hz
THD

@ 3 Ω, 1W, 1KHz

@ 3 Ω, 10W, 1KHz

0.064 %

0.074 %
Livello di rumore in uscita Ponderazione, Ingresso collegato a GND 234 mV
SNR 150 W @ 3 Ω THD + N 1% 95 dB
Temperature
 - 50 °C

Others features AA-AB31392

Parametri Specifiche
Chip T-AMP
Dimensioni 15,2 x 11,4 x 3,8 cm.
Potenza 1 x 1000W
Classe Amplificatore D
Controllo di volume  Opzionale
Protezione da cortocircuiti Si
Protezione da sovratemperatura Si

Performance

Amplificatore Digitale Classe D

Amplificatore Digitale Classe D

Amplificatore Digitale Classe D

Amplificatore Digitale Classe D
