Luxus Audio Vivaldi MV - Class D Amplifier 1x30W @ 8ohm - Balanced input - Vertical Molex

Data sheet

Brand Luxus Audio
Chips TPA3110D2
Output Power [Watt] 30
Channel 1

Vivaldi MV is an amplifier with class D architecture based on the TPA3110D2 chip. The only available channel has an output power of 30 watts on 8 ohms. The amplifier can be powered via an 8V to 26V power supply. This version has a balanced input, a limiter that allows you to reduce the power output and molex vertically.

.

Features

     Measurements: 16 x 7.5 x 4.8cm
     Bluetooth 4.0
     Class D amplifier based on TPA3110D chips
     90% Class D operation efficiency
     Cascade connection
     LED
     8 step limiter
     Molex vertical

.

Data sheet

     Typical voltage: 8V to 26V
     Maximum voltage: 30V
     Maximum voltage current: 3A
     Output power: 30W @ 8ohm
     THD: 0.015%
     S / N: 102dB
     Input sensitivity: 1.5Vrms
     Earnings: 19.5dB
     Oscillator frequency: 310kHz
     Operating temperature: -30 ° C / + 70 ° C
