WONDOM AA-AB31513 - 1x500W@1.5ohm amplifier class D T-AMP
WONDOM AA-AB31513 - 1x500W@1.5ohm amplifier class D T-AMP
WONDOM AA-AB31513 - 1x500W@1.5ohm amplifier class D T-AMP
WONDOM AA-AB31513 - 1x500W@1.5ohm amplifier class D T-AMP

WONDOM AA-AB31513 - [email protected] amplifier class D T-AMP

WONDOM AA-AB31513 - [email protected] amplifier class D T-AMP

SHIPMENT IN 7/10 WORKING DAYS
€69.00

Tax included
rating No review at the moment

Estimated Shipping Costs
Shipping Costs
€12.60
Shipping Time
.
Want to check another country or courier?

You might also like



WONDOM AA-AB31513 - [email protected] amplifier class D T-AMP

The AB31513 1x500W audio amplifier board uses Sure Electronics' T-AMP technology, which features low distortion and low noise level. This amplifier board supports mono amplification using PBTL topology. The fan runs when the heat sink temperature reaches 45 degrees Celsius and stops when the temperature drops to 40 degrees Celsius.

Hence the audible noise and idle power loss brought by the fan may be omitted when the RMS output power is moderate.

Dettaglio di connessione amplificatore in classe D

Features AA-AB31513

Parametri  Condizioni di Test Valori
Corrente massima 500 W @ 1.5 Ohm 40 V
Tensioni di Alimentazione  - 24-40 V
Efficienza 500 W @ 1.5 Ohm 89-94 %
Potenza Inattiva

SD Floating, FAN ON

SD Floating, FAN OFF

10-14 W

9.2-12 W
Frequenza Swhitching SD Floating 730 kHz
Potenza in Standby SD collegato a GND, FAN OFF 0.8-2 W
Sensibilità  di ingresso (RMS) @ 1,5 Ω, 500 W, 1 KHz 812 V
Impedenza di ingresso - 10 KΩ
Guadagno - 28-32 dB
Impedenza di carico minima - 1.5 Ω
Potenza in uscita

@ 1.5 Ω THD + N 1%

@ 1.5 Ω THD + N 10%

393 W

500 W
Larghezza di banda @ ± 3dB @ 1.5 Ω 20-20K Hz
THD

@ 3 Ω, 1W, 1KHz

@ 3 Ω, 10W, 1KHz

0.07 %

0.076 %
Livello di rumore in uscita Ponderazione, Ingresso collegato a GND 319 mV
SNR 150 W @ 3 Ω THD + N 1% 92 dB
Temperature
 - 50 °C

Others features AA-AB31513

Parametri Specifiche
Chip T-AMP
Dimensioni 15,2 x 11,4 x 3,8 cm.
Potenza 1 x 500W
Classe Amplificatore D
Controllo di volume  Opzionale
Protezione da cortocircuiti Si
Protezione da sovratemperatura Si

Performance

Amplificatore Digitale Classe D

Amplificatore Digitale Classe D

Amplificatore Digitale Classe D

Amplificatore Digitale Classe D

WONDOM AA-AB31513
