Visaton TI 100 4" High-End Mid-Range Driver 8 Ohm

10 cm (4") High-End mid-range driver featuring a diaphragm cone made of pure titanium.

Estimated Shipping Costs
Shipping Costs
€16.80
Shipping Time
.
Want to check another country or courier?

You might also like



Visaton TI 100 4" High-End Mid-Range Driver 8 Ohm

10 cm (4") High-End mid-range driver featuring a diaphragm cone made of pure titanium.

.

Highlights

  • Pure titanium cone
  • Double magnet motor
  • Rear plate vented voice coil

.

Product Details

Visaton TI 100 4" High-End Mid-Range Driver 8 Ohm

The carefully designed cone combines with the shape and material of the surround and the adhesives to avoid cone resonance. The shape of the basket with its large aperture and rear-ventilated damper coupled with the open voice coil with its phase plug produce the lowest possible mechanical losses and produce a correspondingly high mechanical Q. As a result of the construction using double magnets the TI 100 - 8 Ohm is also magnetically compensated.

The TI 100 - 8 Ohm is ideal as a mid-bass unit in smaller high end shelf speakers or as a mid-range unit in high-end multi-way Speakers.

Technical Specifications

  • Article number TI 100
  • Woofer Series High-End
  • Woofer Type Midwoofer
  • Nominal Diameter 4"
  • Power Handling (RMS) 40 Watts
  • Power Handling (max) 60 Watts
  • Impedance (Z) 8 ohms
  • Sensitivity (SPL at 1m / 2.83V) 86 dB
  • Frequency Response 62 - 20,000 Hz
  • Voice Coil Diameter 21 mm
  • DC Resistance (Re) 6.4 ohms
  • Voice Coil Inductance (Le) 0.7 mH
  • Resonant Frequency (Fs) 62 Hz
  • Mechanical Q (Qms) 5.95
  • Electromagnetic Q (Qes) 0.44
  • Total Q (Qts) 0.41
  • Diaphragm Mass Inc. Airload (Mms) 4g
  • Mechanical Compliance of Suspension (Cms) 1.37 mm/N
  • BL Product (BL) 4.98 Tm
  • Compliance Equivalent Volume (Vas) 5.68 liters
  • Maximum Linear Excursion (Xmax) 4 mm
  • Cone / Diaphragm Material Titanium
  • Surround Material Rubber
  • Overall Outside Diameter 121.5 mm
  • Overall Depth 76 mm
  • Baffle Cutout Diameter 101 mm
  • Bolt Circle Diameter 111 mm
  • # Mounting Holes 4
  • Mounting Hole Diameter 4.2 mm
