20 cm (8") woofer with very good price/performance ratio. Suitable for simple 2-way speakers and car rear tray systems. Especially suited as replacement driver for many HiFi speakers.

SHIPMENT IN 7/10 WORKING DAYS
€32.95
Tax included
rating No review at the moment

The minimum purchase order quantity for the product is 2.

Estimated Shipping Costs
Shipping Costs
€19.08
Shipping Time
.
Want to check another country or courier?

You might also like



Visaton W 200 - 8 8" Woofer 8 Ohm

20 cm (8") woofer with very good price/performance ratio. Suitable for simple 2-way speakers and car rear tray systems. Especially suited as replacement driver for many HiFi speakers.

.

Highlights

  • Good Price/Performance ratio
  • Great replacement driver for sealed speaker cabinets
  • Foam surround and ribbed paper cone for a classic sound

.

Product Details

Visaton W 200 8" Woofer 8 Ohm
Visaton's W 200 8" woofer is designed to be a high performance replacement speaker at a budget price point. A foam surround and ribbed, treated paper cone offer longevity while capturing that classic sound from the golden era of loudspeakers. A healthy ±10 mm excursion limit allows this driver to pump out some serious bass in many different sized sealed, acoustic suspension cabinets.
A smooth frequency response makes for easy integration with many different tweeters.

Technical Specifications

  • Article number W 200 - 8
  • Woofer Series W Series
  • Woofer Type Midwoofer
  • Nominal Diameter 8"
  • Power Handling (RMS) 50 Watts
  • Power Handling (max) 80 Watts
  • Impedance (Z) 8 ohms
  • Sensitivity (SPL at 1m / 2.83V) 88 dB
  • Frequency Response 46 - 8,000 Hz
  • Voice Coil Diameter 25 mm
  • DC Resistance (Re) 6.8 ohms
  • Voice Coil Inductance (Le) 0.9 mH
  • Resonant Frequency (Fs) 46 Hz
  • Mechanical Q (Qms) 3.2
  • Electromagnetic Q (Qes) 0.79
  • Total Q (Qts) 0.63
  • Diaphragm Mass Inc. Airload (Mms) 14g
  • Surface Area of Cone (Sd) 207 cm2
  • BL Product (BL) 5.9 Tm
  • Compliance Equivalent Volume (Vas) 51 liters
  • Maximum Linear Excursion (Xmax) 2 mm
  • Cone / Diaphragm Material Treated Paper
  • Surround Material Foam
  • Overall Outside Diameter 206 mm
  • Overall Depth 87 mm
  • Baffle Cutout Diameter 185 mm
  • Bolt Circle Diameter 197 mm
  • # Mounting Holes 4
  • Mounting Hole Diameter 5 mm
  • Sealed Volume 73.6 liters
  • Sealed F3 59 Hz
  • Vented Volume 125 liters
  • Vented F3 30 Hz
