17 cm (6.5") HiFi woofer with coated paper cone, elastic rubber surround and inverse dust-cap.

SHIPMENT IN 5-7 WORKING DAYS
€27.45
Tax included
rating No review at the moment

Estimated Shipping Costs
Shipping Costs
€12.60
Shipping Time
.
Want to check another country or courier?

You might also like



Visaton WS 17 E 6.5" HiFi Woofer 8 Ohm

17 cm (6.5") HiFi woofer with coated paper cone, elastic rubber surround and inverse dust-cap.

.

Highlights

  • Flat frequency response for easy system integration
  • Great replacement driver
  • Special basket design

.

Product Details

Visaton WS 17 E 6.5" HiFi Woofer 8 Ohm

This woofer has a balanced frequency response and is suitable as low-midrange driver for 4-way speaker systems. Due to the special basket design especially suitable as replacement driver for many HiFi speakers. Choose the HiFi Visaton WS 17 E 6.5" driver for use as a woofer in small two and three-way speaker designs, as a midrange or midbass in large multi-way systems, or even as a small format personal computer subwoofer.

The rubber surround and treated paper cone resist fatigue and create a warm, natural sound that matches that of the golden age of audio in the 1970s. A low Fs allows this 6.5" speaker to play all the way down into the 40 Hz region, while its upper response extends out to 7,000 Hz.

.

Technical Specifications

  • Article number WS 17 E - 8
  • Woofer Series HiFi Series
  • Woofer Type Midwoofer
  • Nominal Diameter 6.5"
  • Power Handling (RMS) 60 Watts
  • Power Handling (max) 90 Watts
  • Impedance (Z) 8 ohms
  • Sensitivity (SPL at 1m / 2.83V) 88 dB
  • Frequency Response 45 - 7,000 Hz
  • Voice Coil Diameter 25 mm
  • DC Resistance (Re) 5.8 ohms
  • Voice Coil Inductance (Le) 0.9 mH
  • Resonant Frequency (Fs) 45 Hz
  • Mechanical Q (Qms) 2.2
  • Electromagnetic Q (Qes) 1.28
  • Total Q (Qts) 0.81
  • Diaphragm Mass Inc. Airload (Mms) 16g
  • Surface Area of Cone (Sd) 143 cm2
  • BL Product (BL) 3.9 Tm
  • Compliance Equivalent Volume (Vas) 22 liters
  • Maximum Linear Excursion (Xmax) 3.5 mm
  • Cone / Diaphragm Material Treated Paper
  • Surround Material Rubber
  • Overall Outside Diameter 165 mm
  • Overall Depth 79 mm
  • Baffle Cutout Diameter 150 mm
  • Bolt Circle Diameter 175 mm
  • # Mounting Holes 4
  • Mounting Hole Diameter 5 mm
