    Dayton Audio ND16FA-4 5/8" Soft Dome Neodymium Tweeter 4 Ohm

    Dayton Audio's ND16FA-4 5/8" soft dome tweeter is perfect for use in compact 2-way systems such as desktop, surround, or portable speaker systems. With smooth response from 4,000 to 20,000 Hz this tweeter is ideal for adding more top end to many full-range drivers.

    Highlights

    • Ferrofluid enhances power handling and helps damp resonance
    • Powerful neodymium motor keeps tweeter small with impressive efficiency
    • Compact faceplate is perfect for minimal center-to-center distances
    • Easy installation, front mount pressfit design

    Estimated Shipping Costs
    Shipping Costs
    €18.00
    Shipping Time
    .
    Want to check another country or courier?



    Dayton Audio ND16FA-4 5/8" Soft Dome Neodymium Tweeter 4 Ohm

    Dayton Audio's ND16FA-4 5/8" soft dome tweeter is perfect for use in compact 2-way systems such as desktop, surround, or portable speaker systems. With smooth response from 4,000 to 20,000 Hz this tweeter is ideal for adding more top end to many full-range drivers.

    The versatile ND16FA-4 5/8" soft dome tweeter from Dayton Audio has the sensitivity, smoothness, and power handling for use in a 2-way design with most small woofers. The compact faceplate allows minimal center-to-center distances making these a great choice for use in 2-way designs with high crossover points. With 4-ohm impedance, this tweeter is suitable for use in both home and automotive applications. Thanks to the Ferrofluid cooled voice coil, the ND13FA-4 can handle an impressive amount of power and has excellent damping for extremely accurate response.

    .

    Highlights

    • Ferrofluid enhances power handling and helps damp resonance
    • Powerful neodymium motor keeps tweeter small with impressive efficiency
    • Compact faceplate is perfect for minimal center-to-center distances
    • Easy installation, front mount pressfit design

    .

    Product Details

    Speaker Series ND Series
    Model Number ND16FA-4
    Color Black Unit of Measure Each
    UPC 848791004742
    Product Shipping Weight (lbs.) 0.05
    Speaker Type Tweeter
    Nominal Diameter .625"
    Power Handling (RMS) 30 watts
    Power Handling (max) 60 watts
    Continuous Program Power --
    Impedance 4 ohms
    Sensitivity 93 dB 2.83V/1m
    Frequency Response 4,000 - 20,000 Hz
    Voice Coil Diameter 16 mm
    Magnet Weight --
    DC Resistance (Re) 3.17 ohms
    Voice Coil Inductance (Le) 0.03 mH
    Resonant Frequency (Fs) 2246 Hz
    Mechanical Q (Qms) 3.71
    Electromagnetic Q (Qes) 3.46
    Total Q (Qts) 1.79
    Diaphragm Mass Inc. Airload (Mms) --
    Moving Mass Of Diaphragm (Mmd) --
    Mechanical Compliance of Suspension (Cms) --
    Surface Area Of Cone (Sd) --
    Volume of Displacement (Vd) --
    BL Product (BL) --
    Compliance Equivalent Volume (Vas) --
    Maximum Linear Excursion (Xmax) --
    Drivers Mechanical Losses (Rms) --
    Cone / Diaphragm Material Titanium Cone
    Entry / Exit Diameter --
    Surround Material --
    Voice Coil Wire Material Copper
    Voice Coil Former Polyimide
    Basket/Frame Material Plastic
    Magnet Material Neodymium
    Overall Outside Diameter 45 mm
    Overall Depth 14.5 mm
    Baffle Cutout Diameter 11.5 mm
    Mounting Hole Diameter --
    Bolt Circle Diameter --
    Product Weight --
    ND16FA-4
