miniDSP Flex HTx 8x8 Balance & Unbalanced SHARC DSP

Elevate your audio experience with the Flex HTx 8x8 DSP, a groundbreaking digital signal processor designed to transform your home theater or professional audio setup. This remarkable device boasts an 8x8 matrix DSP architecture, enabling simultaneous processing of up to 8 input and 8 output channels, making it an ideal solution for multi-channel audio applications.

.

Highlights:

• Processor: 32-bit floating-point 400MHz Analog Devices SHARC DSP
• Multi-Core USB Audio processor (XMOS)
• HDMI EARC/ARC interface for multichannel audio in PCM. Note that Flex HTx doesn't support bistream format (Dolby/DTS encoded).
• Optional upgrade to Dirac Live® 3.x Digital Room Correction, Multichannel (8ch) Full Range Room Correction (20~20kHz)
• Audiophile performance with very low noise floor and distortion (SNR @127dB(A), THD+N @ -120dB (0.0001%)
• Inputs: Stereo digital (SPDIF/Optical), Multichannel USB Audio streaming (up to 7.1)
• Outputs: 8 channels audio duplicated to unbalanced (RCA)
• White/Black OLED front panel controller with IR control
• Control and configuration by miniDSP Device Console (DC)
• Rack mountable with removeable rack EARS

.

Product details:

miniDSP Flex HTx 8x8 Unbalanced TRS & RCA SHARC DSP

The Flex HTx 8x8 DSP is equipped with premium analog-to-digital (A/D) and digital-to-analog (D/A) converters, ensuring pristine audio reproduction. Its 32-bit floating-point processing delivers exceptional sound quality, capturing the nuances and subtleties of your favorite music and movies.

Embrace the power of Dirac Live room correction, an innovative technology that precisely calibrates your speakers to their environment, resulting in a natural and immersive soundstage. The Flex HTx 8x8 DSP supports a wide range of audio formats, including PCM, DSD, and Dolby Atmos, ensuring compatibility with your existing audio equipment and future high-resolution content.

.

Specifcations:

• Article number Flex HTx
• Device type Balance & Unbalanced SHARC
• DSP DSP chip ADI ADSP21489 @400MHz
• Audio input connectivity RCA + Balanced. Multichannel USB audio (8ch) and EARC/ARC HDMI input (8ch PCM). SPDIF/optical stereo inputs. USB audio (8ch)
• Audio output connectivity RCA + Balanced. Multichannel USB audio (8ch) and EARC/ARC HDMI input (8ch PCM)
• Max input level 4 Vrms
• Max output level 4 Vrms
• Dirac Live® Dirac Live 3.x upgrade option
• DSP presets 4
• UMIK-1 included No
• Dimensions (HxWxD) 41.5 x 429 x 236 mm
• Power 16.5 watt
