miniDSP C-DSP 8x12 V2.0 Boxed Digital Audio Processor for Mobile/Car audio

Premium Digital Audio Processor for Mobile/Car audio installations, 32bit floating point SHARC ADSP21489 @ 400MHz, 8x12 I/O, Remote for Preset/Master & Sub volume control.

.

Product Highlights

• 400MHz 32bit Sharc Floating point processor, Up to 192kHz processing
• Digital and analog inputs (Low/High levels), 12 analog outputs
• Flexible DSP processing blocks, Rear Fill processing (L-R, L+R..) thanks to internal matrix
• Windows/Mac compatible GUI
• Remote control or preset/master & sub volume control
• V2.0

.

Product Details:

miniDSP C-DSP 8x12 V2.0 Digital Signal Processor for Mobile/Car audio

The C-DSP 8x12 is miniDSP’s next-generation processor for high-end mobile/car audio.

The powerful 400 MHz SHARC floating-point processor provides pristine high-resolution audio at internal sample rates up to 192 kHz. With a wealth of inputs and outputs in a compact, rugged enclosure, the C-DSP 8x12 is suitable for installations from simple stereo, through surround systems with subwoofer integration, up to advanced multichannel active systems.

The driverless USB interface is used to configure miniDSP’s powerful but easy-to-use audio processing: parametric EQ on all inputs and outputs, compressors and adjustable time delay on all outputs, crossovers up to 48 dB/octave, and an advanced matrix mixer. Four complete processing configurations are stored in flash memory for instant recall with a wired or infrared remote.

Hardware features dedicated to the vehicle environment include an on-board isolated power supply, remote trigger input/output, a wired remote for dash or console mounting, and a microSD card slot for offline configuration and firmware updates.

Specifications:

• Article number C-DSP 8x12 Boxed
• Device type Boxed
• Device serie Car Audio DSP
• DSP chip Analog Devices ADSP21489
• Processing resolution & sample rate 32 bit / 192 kHz
• Input / ouput configuration 8 / 12
• Audio input connectivity High level (terminal block), low level (RCA), Toslink, SPDIF (RCA)
• Audio output connectivity RCA
• Max input level 8 / 12 Vrms (high level) 2 /4 Vrms (low level)
• Max output level 6 Vrms
• Input impedance 68 ohms (high level / 10k ohms (low level)
• Output impedance 560 ohms
• Calibration software miniDSP C-DSP 8x12 plug-ins
• IIR
• FIR
• Dirac Live® -
• DSP presets 4
• Impulse response correction
• Infrared remote learning
• Windows / Mac compatible /
• UMIK-1 included No
• Room EQ wizard support
• Dimensions 205 x 122 x 41 mm
• Power Isolated DC-DC conversion for 12V Car Audio environment

.

What's included in the box?

• 1 x C-DSP 8x12 V2.0 DSP processor
• 1 x USB cable
• 1 x remote unit
• 1 x 5m long remote cable
• 1 x Coupon code for miniDSP plugin download.
