The W 250 S 10" woofer from Visaton delivers amazing performance not normally found in drivers this size at this price point. A low Qts allows you to get very deep bass in a reasonably sized ported enclosure.

SHIPMENT IN 5-7 WORKING DAYS
€89.95
Tax included
rating No review at the moment

Estimated Shipping Costs
Shipping Costs
€19.08
Shipping Time
.
Want to check another country or courier?

You might also like



Visaton W 250 S - 8 10" HiFi Woofer 8 Ohm

The W 250 S 10" woofer from Visaton delivers amazing performance not normally found in drivers this size at this price point. A low Qts allows you to get very deep bass in a reasonably sized ported enclosure.

.

Highlights

  • Very flat frequency response for easy system integration
  • Great for use as a HiFi woofer or as a subwoofer
  • Great sensitivity combined with low Fs and Qts for high performance

.

Product Details

Visaton W 250 S 10" HiFi Woofer 8 Ohm

This woofer features a coated paper cone, durable rubber surround, and a bumped back plate to an excursion limit of ±7 mm. A balanced design approach between sensitivity, smooth frequency response (cross it over as high as 2,500 Hz), and extended bass allows this driver to be used as a high-output HiFi woofer in three-way speaker systems or as a subwoofer.

.

Technical Specifications

  • Article number W 250 S - 8
  • Woofer Series HiFi Series
  • Woofer Type Midwoofer
  • Nominal Diameter 10"
  • Power Handling (RMS) 100 Watts
  • Power Handling (max) 150 Watts
  • Impedance (Z) 8 ohms
  • Sensitivity (SPL at 1m / 2.83V) 90 dB
  • Frequency Response 31 - 5,500 Hz
  • Voice Coil Diameter 38 mm
  • DC Resistance (Re) 6.6 ohms
  • Voice Coil Inductance (Le) 1.5 mH
  • Resonant Frequency (Fs) 31 Hz
  • Mechanical Q (Qms) 1.88
  • Electromagnetic Q (Qes) 0.39
  • Total Q (Qts) 0.32
  • Diaphragm Mass Inc. Airload (Mms) 38g
  • Surface Area of Cone (Sd) 346 cm2
  • BL Product (BL) 9.2 Tm
  • Compliance Equivalent Volume (Vas) 121 liters
  • Maximum Linear Excursion (Xmax) 5 mm
  • Cone / Diaphragm Material Treated Paper
  • Surround Material Rubber
  • Overall Outside Diameter 283 mm
  • Overall Depth 120 mm
  • Baffle Cutout Diameter 233 mm
  • Bolt Circle Diameter 267 mm
  • # Mounting Holes 5
  • Sealed Volume 22.7 liters
  • Sealed F3 76 Hz
  • Vented Volume 46.7 liters
  • Vented F3 47 Hz
