30 cm (12") high-end woofer with a black cellulose diaphragm, large-format magnet arrangement and a massive aluminum diecast basket.

SHIPMENT IN 5-7 WORKING DAYS
€399.00
Tax included
rating No review at the moment

Estimated Shipping Costs
Shipping Costs
€27.48
Shipping Time
.
Want to check another country or courier?

You might also like



Visaton TIW 300 Subwoofer 12" 8 ohm

30 cm (12") high-end woofer with a black cellulose diaphragm, large-format magnet arrangement and a massive aluminum diecast basket.

.

Highlights

  • Large 65 mm voice coil
  • Cellulose diaphragm
  • Capable of high volume levels

.

Product Details

Visaton TIW 300 12" High-End Woofer

Thanks to the multiple venting of the voice coil (pole piece hole, holes in the pole piece plate, cutouts in the aluminum diecast cone to vent the spider from behind) losses and flow noise are minimized. The combination of the voice coil carrier made of Kapton and the large 65 mm voice coil allow extremely high volume levels.

Technical Specifications

  • Article number TIW 300
  • Woofer Series High-End
  • Woofer Type Midwoofer
  • Nominal Diameter 12"
  • Power Handling (RMS) 300 Watts
  • Power Handling (max) 600 Watts
  • Impedance (Z) 8 ohms
  • Sensitivity (SPL at 1m / 2.83V) 90 dB
  • Frequency Response 31- 4,000 Hz
  • Voice Coil Diameter 65 mm
  • DC Resistance (Re) 5.4 ohms
  • Voice Coil Inductance (Le) 1.7 mH
  • Resonant Frequency (Fs) 25 Hz
  • Mechanical Q (Qms) 4.59
  • Electromagnetic Q (Qes) 0.30
  • Total Q (Qts) 0.28
  • Diaphragm Mass Inc. Airload (Mms) 92g
  • Surface Area of Cone (Sd) 510 cm2
  • BL Product (BL) 16.5 Tm
  • Compliance Equivalent Volume (Vas) 160 liters
  • Maximum Linear Excursion (Xmax) 7.5 mm
  • Cone / Diaphragm Material Cellulose
  • Voice Coil Former Kapton
  • Basket / Frame Material Cast Aluminum
  • Overall Outside Diameter 329 mm
  • Overall Depth 149 mm
  • Baffle Cutout Diameter 288 mm
  • Bolt Circle Diameter 312.5 mm
  • # Mounting Holes 8
  • Mounting Hole Diameter 6.5 mm
