50 mm (2") High-End fabric dome driver for the midrange band between 800 and 7000 Hz.

SHIPMENT IN 5-7 WORKING DAYS
€114.95
Tax included
rating No review at the moment

Estimated Shipping Costs
Shipping Costs
€14.40
Shipping Time
.
Want to check another country or courier?

You might also like



Visaton G 50 FFL 2" High-End Fabric Mid-Dome 8 Ohm

50 mm (2") High-End fabric dome driver for the midrange band between 800 and 7000 Hz.

.

Highlights

  • Fabric dome with optimized shape
  • High efficiency
  • High power handling

Product Details

Visaton G 50 FFL 2" High-End Fabric Mid-Dome 8 Ohm
Due to the optimized dome shape with damping coating in conjunction with the highly damped surround, linear frequency response and no partial oscillations. Due to the powerful magnetic drive and the ferrofluid-cooled voice-coil high efficiency and high power handling can be guaranteed.

.

Technical Specifications

  • Article number G 50 FFL
  • Woofer Series High-End
  • Woofer Type Mid-dome
  • Nominal Diameter 2"
  • Power Handling (RMS) 120 Watts
  • Power Handling (max) 180 Watts
  • Impedance (Z) 8 ohms
  • Sensitivity (SPL at 1m / 2.83V) 90 dB
  • Frequency Response 300 - 12,000 Hz
  • Voice Coil Diameter 50 mm
  • DC Resistance (Re) 6.4 ohms
  • Voice Coil Inductance (Le) 0.16 mH
  • Resonant Frequency (Fs) 455 Hz
  • Mechanical Q (Qms) 0.48
  • Electromagnetic Q (Qes) 0.67
  • Total Q (Qts) 0.28
  • Diaphragm Mass Inc. Airload (Mms) 1.2g
  • Surface Area of Cone (Sd) 20 cm2
  • Compliance Equivalent Volume (Vas) 0.037 liters
  • Cone / Diaphragm Material Fabric
  • Overall Outside Diameter 140 mm
  • Overall Depth 50.2
  • Baffle Cutout Diameter 106 mm
  • Bolt Circle Diameter 126 mm
  • # Mounting Holes 4
  • Mounting Hole Diameter 4.2 mm
