Visaton G 25 FFL Dome Tweeter 25 mm

Visaton G 25 FFL Dome Tweeter 25 mm

25 mm (1") fabric dome driver for the high-frequency range above 2000 Hz.

SHIPMENT IN 5-7 WORKING DAYS
€82.45
Tax included
rating No review at the moment

Estimated Shipping Costs
Shipping Costs
€14.40
Shipping Time
.
Want to check another country or courier?

You might also like



Visaton G 25 FFL Dome Tweeter 25 mm

25 mm (1") fabric dome driver for the high-frequency range above 2000 Hz.

.

Highlights

  • Crossover point from 2,000 Hz and up
  • 90 dB sensitivity
  • Great power handling
.

Product Details

Visaton G 25 FFL 1" Fabric Tweeter
Due to the optimized dome shape with double coating in conjunction with the highly damped surround, linear frequency response has been made possible. Due to the powerful magnetic driver and the ferrofluid-cooled voice-coil high efficiency and high power handling can be guaranteed.
.

Technical Specifications

  • Article number G 25 FFL
  • Tweeter Type Dome
  • Tweeter Series G Series
  • Cone / Dome Diameter 25 mm | 1"
  • Power Handling (RMS) 80 Watts
  • Power Handling (max) 140 Watts
  • Impedance (Z) 8 Ω
  • Sensitivity (SPL at 1m / 2.83V) 90 dB
  • Frequency Response 1,000 - 30,000 Hz
  • Resonant Frequency (Fs) 1600 Hz
  • DC Resistance (Re) 5.6 ohms
  • Voice Coil Inductance (Le) 0.05 mH
  • Overall Outside Diameter 104.5 mm
  • Cutout Diameter 80 mm
  • Depth 26.5 mm
  • Diaphragm Material Fabric
  • Recommended cut frequency >2,000 Hz
