20 mm (0.8") polycarbonate HiFi tweeter from Visaton is designed for high power handling and features smooth frequency response.

SHIPMENT IN 5-7 WORKING DAYS
€29.95
Tax included
rating No review at the moment

The minimum purchase order quantity for the product is 2.

Estimated Shipping Costs
Shipping Costs
€12.60
Shipping Time
.
Want to check another country or courier?

You might also like



Visaton DT 94 - 4 Dome Tweeter 20 mm

20 mm (0.8") polycarbonate HiFi tweeter from Visaton is designed for high power handling and features smooth frequency response.

.

Highlights

  • Ferrofluid-cooled 4 ohm voice coil
  • 90 dB sensitivity
  • High power handling

.

Product Details

Visaton DT 94 - 4 Polycarbonate HiFi Tweeter 8 Ohm

This tweeter features smooth frequency response, high power handling (due to the ferrofluid cooled voice coil) and great dispersion characteristics that are a result of the integrated phase plug.

Technical Specifications

  • Article number DT 94 - 4
  • Tweeter Type Dome
  • Tweeter Series HiFi Series
  • Cone / Dome Diameter 20 mm | 4/5"
  • Power Handling (RMS) 70 Watts
  • Power Handling (max) 100 Watts
  • Impedance (Z) 4 Ω
  • Sensitivity (SPL at 1m / 2.83V) 93 dB
  • Frequency Response 1,200 - 22,000 Hz
  • Resonant Frequency (Fs) 1900 Hz
  • DC Resistance (Re) 3.1 ohms
  • Voice Coil Inductance (Le) 0.09 mH
  • Overall Outside Diameter 94 mm
  • Cutout Diameter 64 mm
  • Depth 23 mm
  • Diaphragm Material Polycarbonate
  • Recommended cut frequency >3,000 Hz
Visaton DT 94 - 4
