25 mm (1") Shielded fabric tweeter for the high range above 3,000 Hz.

SHIPMENT IN 5-7 WORKING DAYS
€23.95
Tax included
rating No review at the moment

The minimum purchase order quantity for the product is 2.

Estimated Shipping Costs
Shipping Costs
€12.60
Shipping Time
.
Want to check another country or courier?

You might also like



Visaton SC 10 N Dome Tweeter

25 mm (1") Shielded fabric tweeter for the high range above 3,000 Hz.

.

Highlights

  • Fabric dome
  • Magnetically shielded
  • Special dome coating for linear frequency response

.

Product Details

Visaton SC 10 N 1" Fabric Tweeter

Linear frequency re-sponse is achieved by a special dome coating and ferrofluid-cooled voice-coil for high power handling.

Suitable for shielded medium sized 2-way combinations for surround center speakers and multi-media systems in conjunction with the shielded full range driver SC 13.

Technical Specifications

  • Article number SC 10 N
  • Tweeter Type Dome
  • Tweeter Series SC Series
  • Cone / Dome Diameter 25 mm | 1"
  • Power Handling (RMS) 100 Watts
  • Power Handling (max) 150 Watts
  • Impedance (Z) 8 Ω
  • Sensitivity (SPL at 1m / 2.83V) 90 dB
  • Frequency Response 1,000 - 20,000 Hz
  • Resonant Frequency (Fs) 1700 Hz
  • DC Resistance (Re) 6.9 ohms
  • Voice Coil Inductance (Le) 0.04 mH
  • Overall Outside Diameter 104 mm
  • Cutout Diameter 85 mm
  • Depth 36.5 mm
  • Diaphragm Material Fabric
  • Recommended cut frequency >3,000 Hz

Visaton SC 10 N
