SB Acoustics SB13PFCR25-4 5" Paper Cone Woofer

Like other SB Acoustics plastic chassis drivers, the SB13PFCR25-4 has a smooth response and is incredible value for money.

Estimated Shipping Costs
Shipping Costs
€18.00
Shipping Time
.
Want to check another country or courier?

You might also like



SB Acoustics SB13PFCR25-4 5" Paper Cone Woofer

.

Product description

Vented reinforced plastic chassis.

Proprietary cone material with natural fibers made in-house.

Soft low damping rubber surrounds for an improved transient response.

Optimized motor system.

Vented coil former for low compression

Non-resonant long-life lead wires.

.

Product details

SB Acoustics SB13PFCR25-4 5" Paper Cone Woofer

The SB13PFCR25-4 by SB Acoustics is a 5-inch 4-ohm midwoofer speaker featuring a blended paper fiber cone, a vented reinforced plastic chassis, and an optimized motor system. Like other SB Acoustics plastic chassis drivers, the SB13PFCR25-4 has a smooth response and is incredible value for money.

.

Specifications

Article numberSB13PFCR25-4
Woofer TypeCone driver
Nominal Diameter5"
Power Handling (RMS)40 Watts
Impedance (Z)4 Ohms
Sensitivity (SPL at 1m / 2.83V)89 dB
Voice Coil Diameter25.4 mm
DC Resistance (Re)3.2 Ω
Voice Coil Inductance (Le)0.56 mH
Resonant Frequency (Fs)44 Hz
Mechanical Q (Qms)2.6
Electromagnetic Q (Qes)0.33
Total Q (Qts)0.29
Diaphragm Mass Inc. Airload (Mms)10.5 g
Mechanical Compliance of Suspension (Cms)1.25 mm/N
Surface Area of Cone (Sd)87 cm2
BL Product (BL)5.3 Tm
Compliance Equivalent Volume (Vas)13.4 liters
Maximum Linear Excursion (Xmax)4.5 mm
Driver's Mechanical Losses (Rms)1.1 kg/s

SB13PFCR25-4
