25 mm (1") High-end magnetically shielded tweeter with ceramic diaphragm for crystal clear perfectly reproduced sound without distortion, even at high volume.

SHIPMENT IN 5-7 WORKING DAYS
€174.95
Tax included
rating No review at the moment

Estimated Shipping Costs
Shipping Costs
€14.40
Shipping Time
.
Want to check another country or courier?

You might also like



Visaton KE 25 SC Dome Tweeter

25 mm (1") High-end magnetically shielded tweeter with ceramic diaphragm for crystal clear perfectly reproduced sound without distortion, even at high volume.

.

Highlights

  • Ceramic dome
  • Great omnidirectional sound distribution at high frequency’s
  • Linearized impedance due to integrated LRC element
.

Product Details

Visaton KE 25 SC 1" High-End Tweeter

This tweeter has a perforated pole piece coupled with the flow-optimized rounded shape, the damping in the cavity and the ventilated voice coil carrier guarantee a very low resonance frequency. The impedance is linearized by means of an integrated LRC element.

This means that the dome can be easily integrated in a network of crossovers. The protective grille is fitted on the inside with an acoustic low-pass filter in the shape of a transparent ring, which does not begin to operate until 25 kHz are achieved, when it damps any material-borne resonance. The grille has the added advantage of improving omnidirectional sound distribution at higher frequencies.

.

Technical Specifications

  • Article number KE 25 SC
  • Tweeter Type Dome
  • Tweeter Series High-End
  • Cone / Dome Diameter 25 mm | 1"
  • Power Handling (RMS) 80 Watts
  • Power Handling (max) 140 Watts
  • Impedance (Z) 8 Ω
  • Sensitivity (SPL at 1m / 2.83V) 89 dB
  • Frequency Response 800 - 25,000 Hz
  • Resonant Frequency (Fs) 1250 Hz
  • DC Resistance (Re) 5.9 ohms
  • Overall Outside Diameter 104.5 mm
  • Cutout Diameter 82 mm
  • Depth 60 mm
  • Diaphragm Material Ceramic
  • Recommended cut frequency >1,500 Hz
Visaton KE 25 SC
