ST 1048 - 28mm Tweeter - Morel Supreme -
ST 1048 - 28mm Tweeter - Morel Supreme -
  • On sale!
ST 1048 - 28mm Tweeter - Morel Supreme -
ST 1048 - 28mm Tweeter - Morel Supreme -

ST 1048 GRAY- 28mm Tweeter - Morel Supreme -

SHIPMENT IN 7-10 WORKING DAYS
€249.00
Tax included
rating No review at the moment

ST 1048 GRAY- 28mm Tweeter - Morel Supreme -

Innovative engineering and an advanced approach to acoustic construction are the reason for Supreme Series tweeters' superior high performance.

Key Features

  • Sold in factory matched pairs
  • 110 mm IDR™ Improved Dispersion Recess aluminum faceplate
  • Flat neodymium motor structure provides maximum flux
  • Hexatech™ voice coil for maximum BL product and power handling
  • Acuflex™ coated dome with the perfect blend of internal damping and rigidity
  • Precisely matched acoustic loading between the dome cavity and rear chamber

Estimated Shipping Costs
Shipping Costs
€18.00
Shipping Time
.
Want to check another country or courier?



ST 1048 GRAY- 28mm Tweeter - Morel Supreme -

Innovative engineering and an advanced approach to acoustic construction are the reason for the superior performance of the Supreme series tweeters. Your voice coils move in a significantly higher magnetic field and always remain there during operation. As a result, the Morel Supreme tweeters offer a more linear excursion, eliminate intermodulation distortion, reduce power compression at high levels and significantly improve bass reproduction.

-

Underhung voice coil

Large Hexatech™ aluminum voice coil

104mm IDR™ Improved Dispersion Recess aluminum face plate

Replaceable Acuflex™ dome / coil assembly

Neodymium flat pancake design magnet

High power handling

Dome Material Acuflex™ hand coated soft dome

Voice Coil Wire Hexatech™ Aluminum

Number Of Layers 2

Magnet System Type Neodymium Flat Pancake

Morel Supreme ST 1048 1 "dome tweeter

-

properties

Item number: ST 1048

Tweeter type. Soft dome

Tweeter series. Supreme Series

Cone / Dome Diameter. 1"

Resilience (QMW). 220 watts

Impedance (Z). 8 ohms

sensitivity. 91.5 dB 1W / 1m

Frequency response. 1,400 to 22,000 Hz

Resonance frequency (Fs). 680 Hz

DC resistance (Re). 5.2 ohms

Mechanical quality (Qms). 0.8

Electromagnetic Q (Qes). 0.65

Total Q factor (Qts). 0.36

outer diameter  4.09 "

Cutout diameter. 2.95 "

depth  1.57 "

Frequency response curve. 1500 to 20KHz

Impedance curve

Mechanical drawing. 104mm outside diameter

ST 1048 GRAY
