Dayton Audio created the ST603-4 to provide a reliable replacement option with a response that comfortably integrates with existing designs, all at a great value. These features also put the speaker designer at an advantage, allowing for a large variety of possible combinations when choosing drivers for their own projects!

-

Highlights

• High sensitivity output designed for pro audio duty
• 1" titanium diaphragm for a detailed response
• Compact Size to fit in the tightest spaces for smaller boxes
• 6,100Hz crossover point is perfect for 3-way designs
• Easily adds detail to any existing system

-

Product Details

Model Number ST603-4

Color Silver/Black

Unit of Measure Pair

UPC 848791008665

Product Shipping Weight (lbs.) 1.4

Speaker Type Tweeter

Nominal Diameter 1"

Power Handling (RMS) 60 watts

Power Handling (max) 120 watts

Continuous Program Power --

Impedance 4 ohms

Sensitivity 106 dB @ 2.83V/1m

Frequency Response 5,000 – 20,000 Hz

Voice Coil Diameter 25.4 mm

Magnet Weight --

DC Resistance (Re) 3.75 ohms

Voice Coil Inductance (Le) 0.078 mH @ 10kHz

Resonant Frequency (Fs) 3,480 Hz

Mechanical Q (Qms) --

Electromagnetic Q (Qes) --

Total Q (Qts) --

Diaphragm Mass Inc. Airload (Mms) --

Moving Mass Of Diaphragm (Mmd) --

Mechanical Compliance of Suspension (Cms) --

Surface Area Of Cone (Sd) --

Volume of Displacement (Vd) --

BL Product (BL) --

Compliance Equivalent Volume (Vas) --

Maximum Linear Excursion (Xmax) --

Drivers Mechanical Losses (Rms) --

Cone / Diaphragm Material PEI

Entry / Exit Diameter --

Surround Material --

Voice Coil Wire Material --

Voice Coil Former --

Basket/Frame Material --

Magnet Material Ferrite

Overall Outside Diameter 83 mm

Overall Depth 62.5 mm

Baffle Cutout Diameter 70 mm

Mounting Hole Diameter --

Bolt Circle Diameter --

Product Weight --

Cone / Dome Diameter --
