miniDSP PWR-ICE125 ICEpower Plate Amplifier
miniDSP PWR-ICE125 ICEpower Plate Amplifier
miniDSP PWR-ICE125 ICEpower Plate Amplifier
miniDSP PWR-ICE125 ICEpower Plate Amplifier

miniDSP PWR-ICE125 ICEpower Plate Amplifier

0miniDSP PWR-ICE125 ICEpower Plate Amplifier

2x125W @ 4Ω or 1 x 450W @ 4Ω DSP plate amplifier, Powered by ICEpower® 125ASX2 module, Ethernet control, FIR + IIR filters

SHIPMENT IN 7-10 WORKING DAYS
€427.45 €449.95 -5%
Tax included
rating No review at the moment

Estimated Shipping Costs
Shipping Costs
€16.80
Shipping Time
.
Want to check another country or courier?

You might also like



miniDSP PWR-ICE125 ICEpower Plate Amplifier

2x125W @ 4Ω or 1 x 450W @ 4Ω DSP plate amplifier, Powered by ICEpower® 125ASX2 module, Ethernet control, FIR + IIR filters

.

Product Highlights

  • DSP Powered plate amplifier
  • FIR + IIR filter options (please consult manual for details)
  • Powered by ICEpower® technology for 2x125W @ 4Ω or 1 x 450W @ 4Ω
  • Windows & Mac IP control
  • Analog & Digital input
  • Multi-unit control via Ethernet

.

Product details

PWR-ICE125 2 x 125 Watt DSP ICEpower Plate Amplifier
Introducing the PWR-ICE125, a DSP powered plate amplifier module for active 2 way loudspeakers or mono subwoofers. Result of the collaborative effort of two innovative technology companies, the PWR-ICEs series key features are:
On the processing side is miniDSP's innovative software & firmware allowing a Plug & Play real time control of the onboard DSP over Ethernet/Wifi networks. Using our Zero Conf technology, multiple modules are automatically discovered and controlled from a single User interface in real time. The onboard Digital Signal Processors (DSP) provide real time all the processing a speaker designers will expect to excel at his crossover design task. These include FIR and IIR filters (biquad input), Parametric Equalizers (PEQ), level, crossovers, comp/limiter, delay and more. The Graphical User Interface (GUI) platform is supported on both Mac and Windows environment.
On the power amplifier side, the ICEpower® modules are complete AC plug-to-speaker amplification audio solutions offering flexible two-channel or bridgeable speaker drive. Their compact size, audiophile audio quality and high power output make them perfect for high-performing audio products. The amplifier is rated for up to 2x125W @ 4Ω or 1 x 450W @ 4Ω.
As for audio connectivity, the PWR-ICE125 is fitted with both analog balanced (XLR) & unbalanced inputs (RCA) to provide maximum compatibility. A digital input (AES-EBU) saves on the A-D conversion for maximum performance while a Digital output (AES-EBU) allows multiple plate amplifiers to be linked to each other.
.

  • Specifications:

  • Article number PWR-ICE125
  • Rated power output 2 x 120 watts at 4 ohms
  • Rated power output bridged 1 x 450 watts at 4 ohms
  • Minimum load 3 ohms
  • Signal-to-noise ratio (SNR) -
  • Distortion 0.003 % THD+N (100 Hz at 1 watt)
  • Distortion bridged 0.003 % THD+N (100 Hz at 1 watt)
  • Amplifier classification Class D
  • Circuit topology ICEpower
  • Efficiency 75 % at 100 watts
  • Frequency response 20 - 20,000 Hz
  • Input impedance 10k ohms (unbalanced) 47k ohms (balanced)
  • Input sensitivity 1/2 Vrms (unbalanced) 2/8 Vrms (unbalanced)
  • Auto turn-on sensitivity -
  • DSP
  • DAC
  • Maximum sampling rate 96 kHz
  • Speaker output channels 2
  • Analog in/out 1/-
  • S/PDIF in/out -/-
  • AES/EBU in/out 1/1
  • Coaxial in/out -/-
  • RCA in/out 1/-
  • XLR in/out 2/1
  • Jack in/out -/- U
  • SB connection -
  • Network connection
  • Bluetooth -
  • Subwoofer pre-out -
  • Auto on/off -
  • Remote control -
  • App control
  • Equalizer (EQ) adjustment
  • Equalizer (EQ) profiles -
  • Phase contro
  • l Crossover frequency adjustment
  • Presets
  • Control software miniDSP plugin
  • Windows/Mac compatible /
  • Power requirements 110 / 240 VAC
  • Power inlet connector IEC C14
  • Standby power consumption -
  • Current limit 20 A
  • Under/over voltage protection -
  • Dimensions (H x W x D) 216 x 153 x 75 mm
  • Cutout dimensions 202 x 139 mm

.

What's included in the Box?

  • 1 x PWR-ICE125 amplifier module
  • 1 x CAT5 patch cable
  • 1 x IEC power cord
  • 4 x black wood screws for mounting
  • 1 x Speaker wire harness to connect amplifier to speaker (60cm long)
  • 1 x Coupon code for miniDSP plugin download
