HiVi DMB-A Dome Midrange Tweeter 5 ohms

Product description

HiVi's DMB-A produces an extraordinarily well-balanced frequency response and is able to provide a natural transition to a tweeter providing an open, and well-pronounced lifelike reprodcution.

.

Highlights

Treated artificial fabric coated dome with a special damping material

Underhung voice coil with an aluminum former

Hi-Vi symmetric double magnet shielded motor structure

Vented design with a large non-resonant acoustic chamber

-

Product details

HiVi DMB-A | 2" | Fabric Dome Midrange Tweeter

The 50 mm dome on the HiVi DMB-A dome midrange is a treated artificial fabric coated with special damping material. The resulting sound is airy and light, but very articulate. The high power handling is a result of the under hung voice coil paired with an aluminum former.

With the DMB-A's shielded symmetric double magnet and vented design, the low distortion on this driver is truly pleasing to the ears.

.

Specifications

• Article number DMB-A
• Tweeter Type Dome Midrange
• Tweeter Series DMB Series
• Cone / Dome Diameter 51 mm | 2"
• Power Handling (RMS) 80 Watts
• Power Handling (max) 150 Watts
• Impedance (Z) 5 Ω
• Sensitivity (SPL at 1m / 2.83V) 92 dB
• Frequency Response 400 to 15,000 Hz
• Resonant Frequency (Fs) 700 Hz
• Overall Outside Diameter 5.71"
• Cutout Diameter 4.02"
• Depth 1.69"
• Mounting Type 6
• Diaphragm Material Paper
