The SB Acoustics SB16PFC25-4-COAX is composed by a vented reinforced plastic chassis and a proprietary cone material with natural made in-house fibers.

SHIPMENT IN 7-10 WORKING DAYS
€109.00
Tax included
rating No review at the moment

Estimated Shipping Costs
Shipping Costs
€14.40
Shipping Time
.
Want to check another country or courier?

You might also like



SB Acoustics SB16PFC25-4-COAX 6" Paper Cone Coaxial

.

Product description

Vented reinforced plastic chassis

Proprietary cone material with natural fibers made in-house

Soft low damping rubber surround for improved transient response

Optimized motor system

Non-resonant long life lead wires

Compact large surround dome tweeter

.

Product details

SB Acoustics SB16PFC25-4-COAX 6" Paper Cone Coaxial

The SB Acoustics SB16PFC25-4-COAX is composed by a vented reinforced plastic chassis and a proprietary cone material with natural made in-house fibers. The soft low damping rubber surround allows an improved transient response. Optimized motor system, non-resonant long life lead wires and compact large surround dome tweeter.

.

Specifications

Article numberSB16PFC25-4-COAX
Woofer SeriesPFC Series
Woofer TypeCoaxial
Nominal Diameter6"
Power Handling (RMS)40 Watts
Impedance (Z)4 ohms
Sensitivity (SPL at 1m / 2.83V)90 dB
Voice Coil Diameter1"
DC Resistance (Re)3.2 ohms
Voice Coil Inductance (Le)0.31 mH
Resonant Frequency (Fs)36 Hz
Mechanical Q (Qms)2.6
Electromagnetic Q (Qes)0.35
Total Q (Qts)0.31
Diaphragm Mass Inc. Airload (Mms)12.5 g
Mechanical Compliance of Suspension (Cms)1.51 mm/N
Surface Area of Cone (Sd)124.7 cm2
BL Product (BL)5.1 Tm
Compliance Equivalent Volume (Vas)1.15 ft.³
Maximum Linear Excursion (Xmax)4.65 mm
SB16PFC25-4 coax
