SB Acoustics Satori MR16P-4 6.5'' Midrange
SB Acoustics Satori MR16P-4 6.5'' Midrange
SB Acoustics Satori MR16P-4 6.5'' Midrange
SB Acoustics Satori MR16P-4 6.5'' Midrange
SB Acoustics Satori MR16P-4 6.5'' Midrange
SB Acoustics Satori MR16P-4 6.5'' Midrange
SB Acoustics Satori MR16P-4 6.5'' Midrange
SB Acoustics Satori MR16P-4 6.5'' Midrange

SB Acoustics Satori MR16P-4 6.5'' Midrange

SHIPMENT IN 7/10 WORKING DAYS
€179.55 €189.00 -5%
Tax included
rating No review at the moment

SB Acoustics Satori MR16P-4 6.5'' Midrange

The SB Acoustics Satori MR16P-4 Midwoofer is a State of The Art Neodymium magnet 6.5" 8 ohm midrange, featuring a proprietary Papyrus Paper cone.

The minimum purchase order quantity for the product is 2.

Estimated Shipping Costs
Shipping Costs
€14.40
Shipping Time
.
Want to check another country or courier?

You might also like



SB Acoustics Satori MR16P-4 6.5'' Midrange

.

Product description

Vented aerodynamic cast aluminum chassis for optimum strength and low compression

Proprietary cone material with EGYPTIAN PAPYRUS™ fibers made in-house

Soft low damping rubber surround for optimum transient response

Advanced BIMAX spider for improved linearity

Powerful optimized low distortion neodymium motor system

Non-conducting fiber glass voice coil former for minimum damping

Extended copper sleeve on pole piece for low inductance and reduced distortion

CCAW voice coil for reduced moving mass

Long life silver lead wires attached 180° apart for improved stability

Vented pole piece and coil former for reduced compression

High piston to chassis diameter ratio

Gasket and bolt hole protrusions for reduced coupling to speaker cabinet

Mode balanced cone for reduced break-up

.

Product details

SB Acoustics Satori MR16P-4 6.5'' Midrange

The SB Acoustics Satori MR16P-4 Midwoofer is a State of The Art Neodymium magnet 6.5" 8 ohm midrange, featuring a proprietary Papyrus Paper cone, a soft low damping optimum response rubber surround, BiMax spider, and a glass fiber former with copper sleeve pole piece. Mode balanced cone to reduce break-up.

Fitted with a 1.5" voice coil. Very open cast frame for minimal reflections. Extended copper clad pole piece for lower distortion. Fs 32Hz, and a fabulous level wide response curve level midrange response, this is a very flexible unit.

.

Specifications

Article numberMR16P-4
Woofer SeriesSatori
Woofer TypeMidwoofer
Nominal Diameter6.5"
Power Handling (RMS)40 Watts
Impedance (Z)4 ohms
Sensitivity (SPL at 1m / 2.83V)92 dB
Voice Coil Diameter1.39"
DC Resistance (Re)3.2 ohms
Voice Coil Inductance (Le)0.11 mH
Resonant Frequency (Fs)31 Hz
Mechanical Q (Qms)4.85
Electromagnetic Q (Qes)0.26
Total Q (Qts)0.25
Diaphragm Mass Inc. Airload (Mms)11.2 g
Mechanical Compliance of Suspension (Cms)2.35 mm/N
Surface Area of Cone (Sd)119 cm2
BL Product (BL)5.2 Tm
Compliance Equivalent Volume (Vas)1.66 ft.³
Maximum Linear Excursion (Xmax)3.1 mm
MR16P-4
