SMSL A100 stereo amplifier 2x80 w

Product Highlights

• German Infineon's new technology Class-D power amplifier chip, higher quality, efficiency up to 92%, further reducing power consumption;
• USB audio input and support for driver-free use;
• Built-in 2 sets of subwoofer signal pre-output, for easy connection with active subwoofer system 2.1 or 2.2;
• Bluetooth 5.0 receiver, Great sound quality, longer transmission distance;
• Built-in low-noise, big-power audio dedicated switching power supply to ensure continuous powering;
• A large number of audio grade components are used to enhance the sound experience;
• High-quality gold-plated input and output terminals;
• Perfect protection circuit for overheating, overcurrent, etc.
• High-quality power adapter specially designed for audio.

.

Product details

SMSL A100 Bluetooth Infineon Class-D Stereo Amplifier

SMSL offers with the A100 a compact and affordable but nevertheless powerful Class-D amplifier, based on an Infineon MA12070 chip allowing it to develop 2x80W under 4Ω. Simple and efficient, the A100 is simple to use and practical. It integrates what's more a Bluetooth 5.0 reception allowing to broadcast its music remotely, directly from a smartphone or a tablet.

The Class-D amplification stage of the A100 is based on an Infineon MA12070 chip, offering a good energy reserve while ensuring a clear and faithful reproduction. This one takes advantage of the MERUS architecture, in which each half-bridge uses four MOSFETS. In addition to its stereo RCA and USB-A input, the A100 embeds a Bluetooth 5.0 receiver allowing you to broadcast your music from a distance, from a connected smartphone for example. The integrated chip supports the aptX transmission codec ensuring very good audio quality and signal stability.

In addition to the classic speaker output, the A100 is equipped with a subwoofer output on stereo RCA. It is thus possible to connect an active subwoofer and thus integrate a 2.1 system.

.

Specifications:

Article number SMSL A100

Product type: Amplifier

Amplifier type: Class-D

Inputs: Bluetooth 5.0, 1x USB-A, 1x Stereo RCA

Outputs: Speaker terminals, 1x Stereo RCA subwoofer output

THD+N: 0.005%

SNR: 103dB

Channel separation: 88dB

Output power: 2x80W @ 4Ω; 2x40W @ 8Ω

Input sensitivity: 180mW

Input impedance: 22kΩ

Supply voltage: 100-240VAC

Consumption: 35W

Minimum load 4 Ω

Signal-to-noise ratio (SNR) 103dB

Distortion 0.005 %

Input impedance 22kΩ

Input sensitivity 180mV

Circuit Topology Infineon MA12070

Speaker output channels 2

Subwoofer output channel 2x pre-output

XLR in/out 1/0

USB USB audio input + support driver-free use

Bluetooth 5.0 apt-X & AAC

Power requirements 100-240VAC

Power consumption 35 Watts (Normal Volume)

Dimensions (D x W x H) 165 x 150 x 43 mm

Weight: 600g

Color: Black

.
