STETSOM BRAVO8K_1 Amplifier mono 1 ohm

Stetsom BRAVO8K – 1 Ohm The BRAVO line was developed for automotive sound lovers who are looking for maximum performance in BASS and SUB BASS.

Its 5Hz to 600Hz frequency response delivers powerful bass with quality and definition, for use with subwoofers and woofers.

.

TECHNICAL SPECIFICATIONS

Stetsom BRAVO BASS 8K MONO Car Subwoofer Amplifier - 1x8000W RMS into 1 ohm

Number of channels 1

RMS power 8000W

RMS power at 1 Ohm 14.4V 8200W

RMS power on 2 Ohm 14.4V 4900W

Supply voltage 9V ~ 17V DC

Frequency Response 5Hz ~ 600Hz (Flat ON)

Low pass crossover 30Hz~250Hz

High pass crossover 5Hz~40Hz

Signal to noise ratio > 90dB

Input sensitivity 200mV

Input impedance 4.8K Ohms

Minimum output impedance 1 Ohm

Consumption with Music Signal 365A

Consumption with Bass Signal 730A

Dimensions (H x D x L) mm 80 x 231.5 x 419 mm

Weight 6,0 Kg
