STETSOM EX21000EQ Amplifier 1 channel 1 ohm

-

New EX21000 EQ - 1 Ohm from EXPORT LINE, the line of automotive amplifiers developed to delight Brazil and the World.

Designed for those looking for high performance and sound fidelity, this EX Line product brings the proven EQ Technology allowing individual equalization for the bands: Bass, Mid Bass and Mid High in addition to the traditional Level, High Pass and Low Pass

Frequency response from 10Hz to 10KHz

With more than 80% efficiency, the EX Line amplifiers are very economical, allowing the user to keep the sound playing longer.

-

Technical specifications

Features EX 21000 EQ - 1 OHM

Number of Channels 1

RMS Power in 1 Ohm 12,6V 21,000W RMS

RMS Power in 2 Ohms 12,6V 12,800W RMS

RMS Power in 4 Ohms 12,6V 8,000W RMS

RMS Power in 1 Ohm 14.4V 23.000W RMS

Power RMS at 2 Ohms 14,4V 14,200W RMS

RMS Power in 4 Ohms 14,4V 9,000W RMS

Frequency Response 10Hz ~ 10KHz

Low Pass Crossover 10Hz ~ 10KHz

High Pass Crossover 50Hz ~ 700 KHz

Signal to Noise Ratio> 90dB

Harmonic Distortion <0.9% THD

Input Sensitivity 0.2V

25K OHMS Input Impedance

Minimum Output Impedance 1 OHM

Consumption with Musical Sign 5.8 ~ 990A

Consumption with Signal Bass 5.8 ~ 1980A

Dimensions (H x W x H) mm 77 x 294 x 614 mm

Weight kg 9.8 kg
