SounDigital 35000.1 EVOX 1 Ohm mono amplifier

SounDigital 35000.1 EVOX 1 Ohm mono amplifier

The EVO X Line brings the latest technology in a compact design with the highest quality components. From a pioneering technology, SounDigital brought to car audio amplifiers something that had not been explored yet. The thermal coupling through RTGP system. The exclusive RTGP system (Thermal Recovery for power generation) assures SounDigital products both greater thermal efficiency and robustness with higher stability.

35000.1 EVOX – 1Ω

Power @ 12.6V @ 4Ω: 1 X 15246 WRMS

Power @ 12.6V @ 2Ω: 1 X 23100 WRMS

Power @ 12.6V @ 1Ω: 1 X 35000 WRMS

Power @ 14.4V @ 4Ω: 1 X 16999 WRMS

Power @ 14.4V @ 2Ω: 1 X 25757 WRMS

Power @ 14.4V @ 1Ω: 1 X 39025 WRMS

Operating Voltage: 8V – 16V

Current Draw (Music): 1715 A

Current Draw (Max): 3429 A

Recommended Fuse (Music): 3500 A

Total Efficiency: 81%

Damping Factor: 200

Frequency Response (-3dB): 5Hz – 500 Hz

SNR: 76dB

Crossover HPF: 5Hz – 30Hz

Crossover LPF: 50Hz – 500Hz

THD + N (10% Rated Power): 0.3%

Product Dimensions: 33.9 x 8.8 x 2.8 in

Product Dimensions: 86.3 x 22.5 x 7.1 cm
