MOSCONI AERO 8|12 DSP high-end sound processor

The new generation of the MOSCONI DSP flagship.

Only rarely are you faced with the task of making “the best” even better. This is also the case with the DSP 8to12 AEROSPACE from MOSCONI, which has always been one of the best DSPs on the market for many years and is still “state of the art” in the high-end segment today. Here, our developers managed to use targeted interventions to raise crucial areas and the sound performance to a new level.

The new AERO 8|12 DSP is now equipped with a BT Plus port and is therefore also compatible with our latest innovation, the BARNIE calibration system. It also now has a universal interface for up to 16 channels.

An “active over-ALL bias” stabilization is responsible for the further increased sound performance, which minimizes distortions occurring in the entire dynamic range.

The channel separation, whether in mixed operation (high level / low level) or when summing the inputs, has also been optimized again (Smart Dual ADC).

For the best connection and installation, the AERO 8|12 DSP now has a USB-C port and a new housing, the shape of which suits modern installations.

,

INPUTS:

• 8 x RCA (Cinch), switchable high/low level with autosense
• 4 of which can be freely selected as prioritized auto-fade / Aux
• 1 x S/PDIF digital optical
• 1 x RCA digital COAX
• 1 x BT slot
• ATOM mixer menu with dynamic preset switching and “trigger” control

.

OUTPUTS:

• 12 x RCA analog
• 1 x S/PDIF optical (freely assignable, volume controlled)
• 12V remote out

.

EQUALIZER:

• Fully parametric 30 band EQ, can also be used graphically, + 12 to - 12 dB, Q: 0.5 - 40
• Fixed sorting: Front channels (1 – 6) Rear channels (9 + 10)
• Assignable channels: 7 + 8 = Front, Rear 11 + 12 = Sub, Center, Free

.

FILTER:

• 10 per channel freely configurable, (setting without sound interruption)
• High pass, low pass, shelf, notch, allpas, peak EQ
• Slope 6 – 120 dB/octave, variable Q, time and level

.

MISCELLANEOUS:

• Compatible with BARNIE calibration system
• Runtime correction 0 – 12 ms (0.005 ms steps) (setting without audio interruption)
• Input delay (channels 1 – 6) to correct delays in factory systems
• Phase reversal 0 - 180°
• Level adjustment outputs (0.5-dB steps)
• Mute function
• 4 x preset memory (switching without interrupting the sound)
• Dimensions: 200 x 125 x 40 mm (including mounting flange)

.

.

.

.

.

.

.

.

.
