SB Acoustics SB34SWPL76-4 Subwoofer
SB Acoustics SB34SWPL76-4 Subwoofer
SB Acoustics SB34SWPL76-4 Subwoofer
SB Acoustics SB34SWPL76-4 Subwoofer
SB Acoustics SB34SWPL76-4 Subwoofer
SB Acoustics SB34SWPL76-4 Subwoofer
SB Acoustics SB34SWPL76-4 Subwoofer
SB Acoustics SB34SWPL76-4 Subwoofer
SB Acoustics SB34SWPL76-4 Subwoofer
SB Acoustics SB34SWPL76-4 Subwoofer
SB Acoustics SB34SWPL76-4 Subwoofer
SB Acoustics SB34SWPL76-4 Subwoofer

SB Acoustics SB34SWPL76-4 Subwoofer

SB Acoustics SB34SWPL76-4 Subwoofer

SB Acoustics is known for their high value products. And the SB34SWPL76-4  is no exception. With a very stiff hard paper cone made in-house.

Out-of-Stock
€246.05 €259.00 -5%
Tax included
rating No review at the moment

The minimum purchase order quantity for the product is 2.


Estimated Shipping Costs
Shipping Costs
€14.40
Shipping Time
.
Want to check another country or courier?

You might also like



SB Acoustics SB34SWPL76-4 Subwoofer

.

Product description

Long stroke design

Linear high stability surround

Low damping rubber surround

3” copper voice coil

Non-conducting reinforced fibre glass coil former

Very stiff hard paper cone (made in-house)

Vented cast aluminum chassis

Large vented motor system and vented coilformer

Long life silver lead wires

.

Product details

SB Acoustics SB34SWPL76-4 12” Paper Cone Subwoofer

SB Acoustics is known for their high value products. And the SB34SWPL76-4  is no exception. With a very stiff hard paper cone made in-house. This allows SB Acoustics to have control over the tolerances used in the manufacturing process. Resulting in a accurate and consistent product. Making this a powerful and exceptionally stable subwoofer for any subwoofer DIY project.

.

Specifications

Article numberSB34SWPL76-4
Woofer TypeSubwoofer
Nominal Diameter12''
Power Handling (RMS)300 Watts
Impedance (Z)4 Ohms
Sensitivity (SPL at 1m / 2.83V)85 dB
Voice Coil Diameter76 mm
Magnet Weight2.4 kg
DC Resistance (Re)3.5 Ohms
Voice Coil Inductance (Le)5.3 mH
Resonant Frequency (Fs)19 Hz
Mechanical Q (Qms)8.6
Electromagnetic Q (Qes)0.34
Total Q (Qts)0.33
Diaphragm Mass Inc. Airload (Mms)266 g
Mechanical Compliance of Suspension (Cms)0.26 mm/N
Surface Area of Cone (Sd)458 cm2
BL Product (BL)18 Tm
Compliance Equivalent Volume (Vas)78.5 Ltr
Maximum Linear Excursion (Xmax)15 mm
Driver's Mechanical Losses (Rms)3.7 kg/s
Cone / Diaphragm Materialpaper
Surround MaterialRubber
Voice Coil Wire MaterialCopper
Voice Coil FormerFibre glass
Basket / Frame MaterialAluminum
Magnet MaterialFerrite
Overall Outside Diameter346 mm
Baffle Cutout Diameter305.2 mm
# Mounting Holes8

SB34SWPL76-4
