Match UP 1FX AMPLIFIER 1x350W Upgrade-amplifier
Match UP 1FX AMPLIFIER 1x350W Upgrade-amplifier

Match UP 1FX AMPLIFIER 1x350W Upgrade-amplifier

Match UP 1FX AMPLIFIER 1x350W Upgrade-amplifier

FOR EU CUSTOMERS

SHIPMENT IN 7/10 WORKING DAYS
€273.00 €300.00 -9%
Tax included
rating No review at the moment

Estimated Shipping Costs
Shipping Costs
€14.40
Shipping Time
.
Want to check another country or courier?

You might also like



Match UP 1FX AMPLIFIER 1x350W Upgrade-amplifier

.

Technical data

Power RMS

- @ 4 Ohm: 1x 350 W

- @ 2 Ohm: 1x 600 W

- @ 1 Ohm: 1x 900 W (Permanent 1 Ohm power only achieved with music signal)

Max. power: up to 1000 watts RMS @ 1 Ohm

Amplifier technology: Class D

Inputs:

- 1 x Cinch

- 2 x high-level speaker input

- 1 x Remote In

- 1 x remote control input

Input sensitivity:

- Cinch 0.5 - 3 volts or 1 - 6 volts

- High level 2.5 - 16 volts or 5 - 32 volts

Input impedance

- Cinch: 8.6 kOhm

- High level: 2.5 - 16 V or 5 - 32 V

Outputs: 1 x speaker output

Output voltage Cinch: 3 volts

Frequency range: 10 Hz - 25,000 Hz

Low pass: 50 Hz - 250 Hz adjustable (can be switched off)

Subsonic: 15 Hz (can be switched off)

High/low pass slope: 12 dB

Subsonic/low pass slope: 12 dB

Signal/noise ratio analog input: 108 dB (A-weighted)

Total harmonic distortion (THD): < 0.002%

Attenuation factor: > 160

Operating voltage: 10.5 - 18 volts (max. 5 seconds down to 6 volts)

Idle current consumption: 1050 mA

Fuse: 2 x 30 A LP mini plug-in fuse

Power consumption: DC 12 V, 80 A max.

Additional features: Active, adjustable crossover, start-stop capability, High-level input with automatic switching on, ADEP.3, DirectDSP function

Dimensions (H x W x D): 46 x 130 x 153 mm

.

Scope of delivery

1 x amplifier MATCH UP 1FX

1 x mounting plates & material

1 x operating instructions

Match UP 1FX
