STETSOM DB500.1_2 Amplifier mono 2 ohm

Stetsom DB500.1 500 rms Digital Bass Module 1 channel 4 ohms Stetsom presented yet another novelty for the automotive sound market: the Stetsom DB 500 rms Digital Bass Amplifier Module 1 channel 4 ohms. Its main differential is that it brings all the advantages of a high-performance module to play the bass, but in a lower power version, being the only one on the market with less than 800w. Mounted on a compact housing with Vulcan line design, it has excellent heat dissipation capacity and also has an integrated ventilation system. It has gain control, LPF cut from 35hz to 250hz, Subsonic filter from 5 to 35hz, bass boost up to 18 decibels and accentuation frequency adjustment from 35 to 60hz.

.

Characteristics:

Number of Channels 1

RMS power 500W RMS

RMS power at 2 Ohms 12.6V 430W RMS

RMS power at 4 Ohms 12.6V 260W RMS

RMS power at 2 Ohms 13.8V 515W RMS

RMS power at 4 Ohms 13.8V 310W RMS

RMS power at 2 Ohms 14.4V 560W RMS

RMS power at 4 Ohms 14.4V 340W RMS

Supply Voltage 9V ~15.5V DC

Frequency Response 5Hz ~250Hz

Low Pass Crossover 35Hz ~250Hz

Crossover High Pass 5Hz ~35Hz (Subsonic)

Signal to Noise Ratio >90dB

RCA Input Sensitivity: 200mV / HIGH INPUT: 1.5V

RCA Input Impedance: 14K Ohms / HIGH INPUT: 1K Ohms

Minimum Output Impedance 2 OHMS

Consumption with Musical Signal 21.5A

Consumption with 43A Bass Signal

Dimensions (H x W x L) mm 55 x 162 x 125.5 mm

Weight Kg 0.75 Kg
