GRS 10PF-8 10" paper cone woofers are ideal replacement speakers for use in sealed-box loudspeaker systems in almost any application.

Out-of-Stock
€21.00
Tax included
rating No review at the moment


Estimated Shipping Costs
Shipping Costs
€19.08
Shipping Time
.
Want to check another country or courier?



GRS 10PF-8 10" Paper Cone Foam Surround Woofer 8 Ohm

GRS 10PF-8 10" paper cone woofers are ideal replacement speakers for use in sealed-box loudspeaker systems in almost any application.

.

Product highlights:

  • Perfect for use in sealed-box home theater and music systems
  • Poly-laminated paper cone, treated foam surround, and polymer dust cap
  • Smooth frequency response with minimal cone breakup

.

Product details

GRS 10PF-8 10" Paper Cone Foam Surround Woofer

GRS 10PF-8 10" paper cone woofers are ideal replacement speakers for use in sealed-box loudspeaker systems in almost any application. Thanks to their carefully optimized parameters, GRS 10PF-8 10" poly-laminated paper cone woofers offer a high degree of compatibility when used as replacement speakers—they also provide excellent performance in new projects, too.

Technical Specifications:

  • Article number 10PF-8
  • Woofer Series Replacement woofer
  • Woofer Type Midwoofer
  • Nominal Diameter 10"
  • Power Handling (RMS) 110 Watts
  • Power Handling (max) 220 Watts
  • Impedance (Z) 8 ohms
  • Sensitivity (SPL at 1m / 2.83V) 87 dB
  • Frequency Response 40 to 5,000 Hz
  • Voice Coil Diameter 1.5"
  • DC Resistance (Re) 7.56 ohms
  • Voice Coil Inductance (Le) 1.19 mH
  • Resonant Frequency (Fs) 43 Hz
  • Mechanical Q (Qms) 5.32
  • Electromagnetic Q (Qes) 1.66
  • Total Q (Qts) 1.27
  • Compliance Equivalent Volume (Vas) 2.27 ft.³
  • Maximum Linear Excursion (Xmax) 3 mm
  • Cone / Diaphragm Material Treated Paper
  • Magnet Material Ferrite
  • Overall Outside Diameter 10"
  • Overall Depth 4.125"
  • Baffle Cutout Diameter 9.25"
  • # Mounting Holes 4
  • Sealed Volume 1.87 ft.³
  • Sealed F3 45 Hz
  • Vented Volume 21.49 ft.³Vented F3 24 Hz

GRS 10PF-8

.

As the name “Great Replacement Speakers” might suggest, GRS originally intended to be a fair-priced speaker replacement provider. While GRS stays true to its roots, their affordable but durable replacement speakers received such a good reputation that they fulfil their original destiny and became a great choice for DIY projects. GRS is characterized by excellent quality and good performance for a reasonable price. GRS's focus is on being great replacement speakers. Therefore, GRS offers a broad range of car replacement speakers, especially for BMW car speakers. Have fluctuating temperatures, and too much sunlight caused permanent damage to your car speakers? Then GRS might be a good solution. Next to that, GRS also focuses on woofers and tweeters that a specially designed for vintage speaker models. In fact, their drivers are not only great for repairing vintage hi-fi speakers but also for upgrading them. GRS loudspeaker drivers offer a wide selection, from high-quality paper cone woofers to affordable yet extra-durable long-life polypropylene cone woofers.

GRS RSB901-1 Replacement Speaker Driver for Bose 901 4-1/2" 1 Ohm

This driver's parameters were carefully optimized to match the performance of the classic Bose® 901® loudspeaker systems. Who doesn’t know the legendary Bose 901 speaker?! Featuring a blue paper cone, every speaker cabinet contains four woofers. The GRS RSB901 will make your Bose 901 sound the way it used to. This driver's parameters were carefully optimized to match the performance of the classic Bose® 901® loudspeaker systems. Individually or in multiples, replacing your legendary but ageing speakers has never been easier—or achieved better results. Every RSB901 speaker has been hand checked and tested. It features a premium-quality motor structure resulting in maximum performance and reliability for a good price.

GRS 10SW-4 10" Poly Cone Subwoofer 4 Ohm

The GRS 10SW-4 poly cone subwoofer is a true bargain in replacement subwoofers. Now you can replace blown or damaged subwoofers with new drivers that equal or outperform the original! These economical subs feature a large diameter voice coil, durable polypropylene cone, and extended excursion for high-energy bass reproduction. GRS poly cone subwoofers are not only the perfect replacement for tired, worn-out subwoofers in a variety of audio gear, but they are also a great choice for new designs. Their handsome polypropylene cones provide durability and good looks. Simultaneously, the large vented magnet assemblies and extended voice coils enable long-throw performance and authoritative bass in a variety of enclosures.

GRS PRT-8 Phenolic Ring Tweeter Replacement for AR-4X CTS Marantz and More 8 Ohm

The GRS PRT-8 is a faithful reproduction of the classic "phenolic ring" tweeter from the 60s and 70s featuring an orange colour, developed by CTS and is used by Marantz, Altec, and many others! The GRS PRT-8 is characterized by high efficiency and a flat response. It is described as extremely versatile; great for repairing older systems or for new custom projects.
