Wavecor SW178WA01 bass aluminium 8 ohm 16 cm
Wavecor SW178WA01 bass aluminium 8 ohm 16 cm

Wavecor SW178WA01 bass aluminium 8 ohm 16 cm

SHIPMENT IN 5-7 WORKING DAYS
€143.00
Tax included
rating No review at the moment

Wavecor SW178WA01 bass aluminium 8 ohm 16 cm

Estimated Shipping Costs
Shipping Costs
€14.40
Shipping Time
.
Want to check another country or courier?

You might also like


SW178WA01 7” alu-cone subwoofer, 8 ohm
SW178WA01 is a woofer designed for dedicated subwoofer
applications. It works equally well for high-end hi-fi, high quality
home theater systems, and top multimedia setups.
FEATURES
• Very rigid aluminium cone to ensure piston motion at high levels and for better
heat transfer at high continuous power levels
• Vented voice coil former for reduced distortion and compression
• Vented center pole with dual flares for reduced noise level at large cone
excursions
• Vented chassis for lower air flow speed reducing audible distortion
• Heavy-duty black fiber glass voice coil bobbin to reduce mechanical losses
resulting in better dynamic performance and low-level details
• Large motor system with 1½” voice coil diameter and 110mm magnet for better
control and efficiency
• Built-in alu field-stabilizing ring for reduced high-level distortion
• Long linear stroke motor for reduced distortion at high levels
•
Linear suspension with specially designed CONEX damper (spider) for long
durability under extreme operating conditions
• 4-layer voice coil for increased control and better small-cabinet performance
• Gold plated terminals to prevent oxidation for long-term reliable connection
• Sealing gasket pre-attached for hassle-free mounting and secure cabinet sealing
16 cm bass driver with aluminium cone.
  • power handling (continuous/programme) = 100 W
  • frequency range = 35-400 Hz
  • resonance frequency fs = 36 Hz
  • impedance R = 8 Ohm
  • sound pressure level SPL = 85 dB (2,83V; 1m)
  • DC resistance Re = 6,4 Ohm
  • force factor BL = 12 N/A
  • voice coil inductance L = 2,2 mH
  • effective piston radiating area Sd = 131 cm2
  • effective mechanical mass incl. air load mms = 35 g
  • equivalent volume of compliance Vas = 13,6 l
  • total Q factor Qts = 0,34 (Qms=18,4, Qes=0,35)
  • voice coil diameter = 38,8 mm
  • maximum peak linear excursion vibration xlin = +/- 5 mm
  • mounting diameter d = 142 mm
  • overall diameter d = 178 mm
  • mounting depth (not countersunk) t = 76 mm
  • mass m = 1,81 kg
SW178WA01
